| Scanning Characteristics |
| Scan Element Frequency |
|
|
| Performance Characteristics |
| Interfaces Supported |
RS-232 (Serial) – Standard Serial CableUSB – Standard USB Smart Cable |
| Memory Capacity |
150 bar codes (Default) (Variable Settings) 300 UPC only codes400, 13 character codes (time/stamp turned off) |
| Software Tools |
The CS1504 SDK is available free of charge to all program developers andcan be downloaded fromwww.motorola.com/enterprisemobility/devzone |
| Special Features |
Scan and Delete Buttons: Can be used to add or delete data |
|
Disable Delete Function: Smaller delete button can be disabled via host command |
|
Data Protection Mode: Scan buttons can be locked to prevent accidental deletion/addition of data (default is disabled) |
|
| Data Capture Characteristics |
| Decoding Capability |
UPC/EAN/JAN, Code 128, Code 39, Coupon Code, I2 of 5, D2 of 5, ISBN, Webcodes |
|
| Power Specifications |
| Battery Life |
Up to 5,000 scans on a fresh setof batteries |
| Battery Operated |
Uses four silver oxide watch batteries which are readily available at many stores |
|
| Environment Characteristics |
| Ambient Light Tolerance |
Tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting conditions. Fluorescent, Incandescent, Mercury Vapor, Sodium Vapor, LED1: 450 Ft Candles (4,844 Lux) Sunlight: 8000 Ft Candles (86,111 Lux) |
| Humidity |
0-95% noncondensing |
| Operating Temperature |
41° to 104° F /5° to 40° CS |
| Real Time Clock |
A date/time stamp is recorded with each bar code scanned |
| Storage Temperature |
-4° to 140° F /-20° to 60°C(without batteries) |
|
| Physical Characteristics |
| Dimensions |
2.5 in. L x 1.5 in. W x .75 in. H / 6.35 cm L x 3.81 cm W x 1.90 cm H |
| Weight |
With batteries: 1.2 oz. /34 gm |
|
| Options |
| Regulatory Approvals |
Laser Safety: IEC Class 1, CDRH Class II |
|
EMI/RFI: FCC Part 15 Class B, ICES-003 Class B, European Union EMC Directive,Australian SMA |
