| Scanning Characteristics |
| Motion Tolerance |
Motion Tolerance 25 IPS |
| Print Contrast |
(Minimum) 25% |
| Reading Angle |
Pitch: +/- 40°; Roll (Tilt): 360°; Skew (Yaw): +/- 40° |
| Scan Resolution(Maximum) |
High Density (HD): 1D Linear: 0.077 mm / 3 mils ,Data Matrix: 0.127 mm / 5 mils ,PDF417: 0.102 mm / 4 mils . |
|
Standard Range (SR):1D Linear: 0.102 mm / 4 mils ,Data Matrix: 0.178 mm / 7 mils ,PDF417: 0.127 mm / 5 mils . |
|
| Performance Characteristics |
| Image Capture |
Graphic Formats: BMP, JPEG, TIFF; Greyscale: 256, 16, 2 |
| Imager Sensor |
Wide VGA: 752 x 480 pixels |
| Indicators |
Cradle Indicator LE Ds Battery Charging (Red); Charge Completed (Green); Power/Data (Yellow) |
| Interface |
RS-232 / IBM 46XX / USB Multi-Interface;RS-232 / USB / Keyboard Wedge / Wand Multi-Interface |
| Light Source |
Aiming: 650 nm VLD |
| Reading Indicators (Beeper Operation) |
(Adjustable Tone); Datalogic ‘Green Spot’ Good ReadFeedback; Good Read LED |
|
| Communication Modules |
| Cordless Communications |
Bluetooth Wireless Technology :Piconet: Max. Readers per Radio Receiver: 7 (when using anexternal Piconet dongle); Profiles: SPP (Serial Port Profile)Protocol: Bluetooth 2.0 Certified Class 2; Radio Frequency:2.4 GHzRadio Range (Open Air): 30.0 m / 98.4 ft; Range distances aremeasured using the base station. Range with connection toother Bluetooth peripherals may show different results.Security: Data Encryption; Scanner Authentication |
|
| Data Capture Characteristics |
| Decoding Capability |
2D Codes :Aztec Code; China Han Xin Code; Data Matrix; MaxiCode;QR Code |
|
1D / Linear Codes :Autodiscriminates all standard 1D codes including GS1DataBar™ linear codes. |
|
Postal Codes : Australian Post; China Post; IMB; Japanese Post; KIX Post;Korea Post; Planet Code; Postnet; Royal Mail Code (RM4SCC) |
|
Stacked Codes :EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBarExpanded Stacked; GS1 DataBar Stacked; GS1 DataBar StackedOmnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/EComposites |
|
| Power Specifications |
| Battery |
Battery Type:Lithium-Ion, 2100 mAh; Charge Time:External Power: 4 Hours @ 12 VDC; Reads per Charge: 50,000 |
| Current Consumption |
Current Charging (Typical): < 8 W; Operating (Typical): < 2.5 W @ 5VDC;Standby/Idle (Typical): < 2.5 mA @ 5 VDC |
| Input Voltage |
4.5 – 14.0 VDC |
|
| Environment Characteristics |
| Ambient Light Levels |
0 – 100,000 lux |
| Drop Specification |
Drop Resistance Withstands repeated drops from 1.8 m / 5.9 ft onto a concretesurface |
| Electrostatic Discharge (ESD Protection ) |
(Air Discharge) 16 kV |
| Environment Sealing |
Particulate and Water Sealing IP52 |
| Humidity |
(Non-Condensing) 0 – 95% |
| Operating Temperature |
Temperature Operating: 0 to 50 °C / 32 to 122 °F |
| Storage Temperature |
Storage/Transport: -20 to70 °C / -4 to 158 °F |
|
| Physical Characteristics |
| Dimensions |
Cradle: 18.6 x 9.9 x 5.6 cm / 7.25 x 3.9 x 2.2 inReader: 18.1 x 7.1 x 10.0 cm / 7.1 x 2.8 x 3.9 in |
| Weight |
Cradle: 246 g / 8.68 oz; Reader: 245 g / 8.64 oz |
| Color |
Black; White |
|
| Options |
| Accessories |
Base Stations/Chargers:BC4010-BK-BT Base/Charger, POS Multi-Interface, BlackBC4010-WH-BT Base/Charger, POS Multi-Interface, WhiteBC4030-BK-BT Base/Charger, Standard Multi-Interface, BlackBC4030-WH-BT Base/Charger, Standard Multi-Interface, WhiteCHR-GM40-BK Charging Only Base Station, BlackCHR-GM40-WH Charging Only Base Station, WhiteBatteries/Battery Chargers:RBP-GM40 Removable Battery Pack |
| Regulatory Approvals |
The product meets necessary safety and regulatory approvalsfor its intended use.The Quick Reference Guide for this product can be referred tofor a complete list of certifications. |
| Safety Standards |
Environmental Compliance: Complies to China RoHS; Complies to EU RoHSLaser Classification: Caution Laser Radiation – Do not stare into beam; IEC 60825Class 2 |
| User Options |
Utilities:Datalogic Aladd in™ : Datalogic Aladdin configuration program is available fordownload at no charge.OPOS / JavaPOS JavaPOS : Utilities are available for download at no charge.OPOS Utilities are available for download at no charge.Remote Host Download : Lowers service costs and improves operations: BC4010 |
