| Scanning Characteristics |
| Min. Element Width |
7 mil/0.191 mm |
| Print Contrast |
25% minimum reflective difference |
| Scan Angle |
Roll (Tilt):1 ± 10° from normalPitch:2 ± 65° from normalSkew (Yaw):3 ± 60° from normal |
| Scan Pattern |
Retrocollective |
| Scan Rate |
Scan Repetition: 36 scans per second typical |
|
| Performance Characteristics |
| Interface |
RS232, Keyboard Wedge, WandEmulation, Scanner Emulation,IBM 468X/469X, USB and Synapse |
| Light Source |
650 nm visible laser diode |
|
| Data Capture Characteristics |
| Decoding Capability |
2D Codes :PDF417, microPDF417, MaxiCode, DataMatrix (ECC 2000), Composite Codes, QR Code |
|
Postal Codes: U.S. Postnet, U.S. Planet, U.K. Postal, Japan Postal, Australian Postal, Dutch Postal |
|
DPM Marks (DPM unit only): Data matrix marks applied by dot peening, laser etching, molding, stamping or casting methods to multiple substrates including metal, plastic or glass |
|
1D Codes :UPC.EAN, UPC.EAN with Supplementals, UCC.EAN 128, JAN 8 & 13, Code 39, Code 39 Full ASCII, Code 39 Trioptic, Code 128, Code 128 Full ASCII, Codabar (NW7), Interleaved 2 of 5, Discrete 2 of 5, Code 93, MSI, Code 11, Code 32, Bookland EAN, IATA, UCC/EAN RSS and RSS variants |
|
| Power Specifications |
| Power Availability |
Depending on host: Host power , External power supply |
| Power Requirements |
4.5 – 14 VDC |
| Stand-by Current |
50 mA |
|
| Environment Characteristics |
| Ambient Light Levels |
Ambient Light Immune to direct exposure of normalImmunity: office and factory lighting conditions, aswell as direct exposure to sunlight;Indoor: 450 ft. candles/4,84 LUX;Outdoor: 4,000 ft. candles/43,040 LUX |
| Drop Specification |
Unit functions normally after repeated6.5 ft./2 m drops to concrete |
| Electrostatic Discharge (ESD Protection ) |
Conforms to 20 kV air discharge and 8 kV ofcontact discharge |
| Environment Sealing |
Sealed to IP65 specifications |
| Humidity |
5% to 95% relative humidity, non-condensing |
| Operating Temperature |
-22° to 122° F/-30° to 50° C |
| Storage Temperature |
-40° to 158° F/-40° to 70° C |
|
| Physical Characteristics |
| Dimensions |
7.34 in. H x 4.82 in. W x 2.93 in. D18.65 cm H x 12.25 cm W x 7.43 cm D |
| Weight |
(w/o cable): 12.56 oz./356 g |
| Color |
Twilight Black/Yellow |
|
| Options |
| Regulatory Approvals |
Input Transient :IEC 1000-4-(2,3,4,5,6,11) Protection:EMI/RFI: FCC Part 15 Class B, ICES-003 Class B,European Union EMC Directive, JapanVCCI/MITI/DentoriLaser Safety: IEC825-1 Class 2 |
