| Scanning Characteristics |
| Depth Of Field |
Decode Zone/ Near/ Far:-Code 39 – 7.5 mil/ 8.5 in./21.6 cm 3/4 in./86.4 cm. |
| Motion Tolerance |
Motion Tolerance Up to 60 in./sec. (1.52m/sec.) for 100% 13 mil UPC; motion tolerance will vary depending on code type, scan distance and print quality |
| Scan Angle |
Roll/Pitch/Yaw 360°, ±60°, ±60° |
|
| Performance Characteristics |
| Interface |
InterfacesSupported:USB, RS-232, RS-485 (IBM 46xx Protocols), Keyboard Wedge,Synapse |
| Light Source |
Aiming pattern: 650nm visible laser diodeIllumination: 630nm LED |
|
| Communication Modules |
| Data Rate |
720 Kbps |
| Frequency |
2.402 to 2.480 GHz adapative frequency hopping andco-existence with 802.11 wireless networks |
| Radio |
Bluetooth, Serial Port and HID Profiles |
| Radio Range |
Radio range: Up to 300 ft. (100m) direct line of sight in open air.typical indoor cordless range is 100 ft. (33m), but range will vary depending upon environment |
|
| Data Capture Characteristics |
| Decoding Capability |
Postal :U.S. Postnet, U.S. Planet, U.K. Postal, Japan Postal, Australian Postal, Dutch Postal, 4 State Postal |
|
IUID Support :Supports IUID parsing  the ability to read and separate IUID fields per application requirements |
|
2D Codes :TL C-39, Aztec (Standard, Inverse), MaxiCode, DataMatrix/ECC200 (Standard, Inverse), QR Code (Standard, Inverse, Micro) |
|
1D Codes :UPC/EAN (UPCA/UPCE/UPCE1/EAN-8/EAN-13/ JAN-8/JAN-13plus supplementals, ISBN (Bookland), ISSN, Coupon Code), Code39 (Standard, Full ASCII , Trioptic), Code 128 (Standard, Full ASCII ,UCC/EAN-128, ISBT-128 Concatenated), Code 93, Codabar/NW7, Code 11 (Standard, Matrix 2 of 5), MSI Plessey, I 2 of 5(Interleaved 2 of 5 / IT F, Discrete 2 of 5, IATA , Chinese 2 of 5),GS1 DataBar (Omni-directional, Truncated, Stacked, StackedOmni-directional, Limited, Expanded, Expanded Stacked, Inverse),Base 32 (Italian Pharmacode)PDF417 (and Variants):PDF417 (Standard, Macro), microPDF417 (Standard, Macro),Composite Codes (CC-A, CC-B, CC-C) |
|
| Power Specifications |
| Battery Charging time |
Battery Charge Time Fully charged (100%) in 4.5 hours |
| Battery Type |
DS3578 only: 2200 mAh Lithium Ion Battery (note that DS3508does not require a battery) |
| Cradles |
Fast rate charge2:915 mA @5V 915 mA @5V660 mA @9V 660 mA @9V |
|
Slow rate charge3:480 mA @5V 480 mA @5V345 mA @9V 345 mA @9V |
|
STB 3508 andFLB 3508 | STB3578 andFLB 3578:-Power Reqs. 4.75-14 VDC| 4.75-14 VDC Not charging:10 mA @5V 105 mA @5V45 mA @9V 110 mA @9V |
|
| Environment Characteristics |
| Ambient Light Levels |
Sunlight – 8,000 ft. candles (86,000 LUX); Incandescent;Fluorescent; Mercury Vapor; Sodium Vapor – 150 ft. candles(1,600 LUX); Immune to direct exposure to normal office andfactory lighting conditions, as well as direct exposure to sunlight |
| Drop Specification |
Functions normally after repeated 6.5 ft. (2 m) drops to concrete |
| Electrostatic Discharge (ESD Protection ) |
+/- 15kV air discharge and +/-8kV contact discharge |
| Environment Sealing |
Sealed to IP65 specifications |
| Humidity |
5% to 95% relative humidity, non-condensing |
| Operating Temperature |
-4° F to 122° F/-20° C to 50° C |
| Storage Temperature |
-40° F to 140° F/-40° C to 60° C |
|
| Physical Characteristics |
| Dimensions |
7.34 in. L x 4.82 in. W x 2.93 in. D18.65 cm H x 12.25 cm W x 7.43 cm D |
| Weight |
DS3508-ER (without cable): 12.8 oz. (363 grams)DS3578-ER: 13.79 oz. (391 gm) |
| Color |
Twilight Black/Yellow |
|
| Options |
| Accessories |
Holster; Intelli-stand; tool balancer pulley (tethered); standardcradle (charge only; radio/charge); forklift cradle (charge only;radio/charge) |
| Regulatory Approvals |
Electrical Safety :UL60950-1, CSA C22.2 No. 60950-1, EN 60950-1 / IEC 60950-1Laser Safety :EN 60825-1, IEC 60825-1, 21CFR1040.10, CDRH Class II , IEC Class 2EMI/RFI :FCC Part 15 Class B, ICES-003 Class B, EN 55022, EN 55024, AS/NZS 4268:2008, Japan VCCIEnvironmental Compliant :with RoHS directive 2002/95/EEC |
