| Scanning Characteristics |
| Print Contrast |
Minimum 25% absolute dark/lightreflectance |
| Reading Perfomance |
DS457-SR / DS457-DL:-Paper Label | English | Metric:Code 39 – 3 mil | Not Tested |Not Tested,UPC – 13 mil | 1.5″ – 15.3″ | 3.8 – 38.9 cm,Datamatrix – 4 mil | Not Tested | Not Tested,QR Code – 5 mil | Not Tested | Not Tested,PDF417 – 4 mil | Not Tested | Not Tested. |
|
DS457-HD / DS457-DP:-Label Density |English |Metric:Code 39 – 3 mil | 1.2″- 4.8″ | 3.0 – 12.2 cmCode 39 – 5 mil | 1.1″ – 5.7″ | 2.8 – 14.5 cmCode 39 – 20 mil | 1.9″ – 9.7″ | 4.8 – 24.6 cmUPC – 13 mil | 1.7″ – 8.3″ | 4.3 – 21.1 cmDatamatrix – 4 mil | 1.6″- 3.0″ | 4.1 – 7.6 cmDatamatrix – 5 mil | 1.4″ – 3.7″ | 3.6 – 9.4 cmDatamatrix – 7.5 mil | 1.2″- 4.4″ | 3.0 – 11.2 cmDatamatrix – 10 mil | Not Tested |Not TestedDatamatrix – 15 mil | Not Tested |Not TestedQR Code – 5 mil |1.5″- 3.1″ | 3.8 – 7.9 cmQR Code – 7.5 mil |1.1″- 4.0″ |2.8 – 10.2 cmQR Code – 10 mil | 1.1″- 4.6″ | 2.8 – 11.7 cmPDF417 – 4 mil |1.4″ – 3.8″ | 3.6 – 9.7 cmPDF417 – 6.67 mil |1.0″- 4.8″ |2.5 – 12.2 cmPDF417 – 10 mil | Not Tested | Not TestedPDF417 – 15 mil |Not Tested |Not Tested |
|
| Performance Characteristics |
| Image File Formats |
BMP, TIFF, JPG |
| Imager Field Of View |
DS457 SR and DL: 39.6° horizontal, 25.7°verticalDS457 HD and DP: 38.4° horizontal, 24.9°vertical |
| Interface |
9-pin male D-sub – USB (full speed) and TTLlevel RS232 with RTS and CTS |
| Light Source |
Aiming Element 655 ± 10 nm (VLD)Illumination Element 625 ± 5 nm (LED) |
| Models |
DS457SR: 1D and 2D bar codesDS457HD: 1D and 2D bar codes, including high density codesDS457DL: 1D and 2D bar codes plus parsing of codes found on driver’s licenses and other identification documentsDS457DP: 1D and 2D bar codes plus direct part marks |
| Sensor Resolution |
752 (H) x 480 (V) gray scale |
|
| Data Capture Characteristics |
| Decoding Capability |
1D :All major 1D bar codes |
|
2D :PDF417, DataMatrix, QR Code, Aztec,Composite Codes and MaxiCodePostal US Postnet, US Planet, UK Postal, AustralianPostal, Japan Postal |
|
| Power Specifications |
| Power Maximum |
5 VDC +/- 10% @ 450 mA |
|
| Environment Characteristics |
| Ambient Light Levels |
Total darkness to 9000 ft. candles (96,900 Lux) |
| Drop Specification |
Withstands multiple 30 in./76 cm dropsto concrete |
| Environment Sealing |
Sealing IP54 |
| Humidity |
Operating: 95% RH, non-condensing at 50°CStorage: 85% RH, non-condensing at 70°C |
| Mechanical Shock |
Power mode, trigger mode, beeper tone,session time, focus control, camera control,image control, advanced data formatting,document capture, signature capture |
| Operating Temperature |
-4° to 122° F /-20° to 50° C*(NOTE: Laser aimer disabled above 113° F /45°c |
| Storage Temperature |
-40° to 158° F /-40° to 70° C |
|
| Physical Characteristics |
| Dimensions |
1.15 in. H x 2.3 in. L x 2.44 in. W2.92 cm H x 5.84 cm L x 6.2 cm W |
| Weight |
3.9 oz./111 g |
|
| Options |
| Regulatory Approvals |
Electrical Safety :ETL, VDE, CETL, EN60950, Ctick, VCCILaser Classification: Intended for use in CDRH Class II/IEC 825Class I devicesEMI/RFI :FCC Part 15 Class B, ICES-003 Class B,CISPR22 Class BEnvironmental :RoHS compliant |
| User Options |
Models :DS457SR: 1D and 2D bar codesDS457HD: 1D and 2D bar codes, includinghigh density codesDS457DL: 1D and 2D bar codes plus parsingof codes found on driver’s licenses and otheridentification documentsDS457DP: 1D and 2D bar codes plus directpart marks |
