| Scanning Characteristics |
| Motion Tolerance |
Horizontal velocity: 5 in. (12.7) cm per second |
| Print Contrast |
25% minimum reflectance |
| Reading Perfomance |
(DC – Document Capture focus):5 mil (Code 39) / 2.5 – 10 in. /(6.5 – 25.4 cm)13 mil (100% UPC/EAN) / 0.8 – 16.8 in. /(2 – 42.7 cm)20 mil (Code 39) / 0.7 – 28.3 in. /(1.8 – 71 cm) PDF417 (10 Mil) /1.9 – 11.8 in./ (4.8 – 30 cm)Datamatrix (10 Mil) /2.6 – 12.2 in. /(6.6 – 31 cm) |
|
(SR – Standard Range focus):5 mil (Code 39) /1.1 – 6.5 in. (2.8 – 16.5 cm),13 mil (100% UPC/EAN) /0.5 – 9.7 in. (1.3 – 24.6 cm),20 mil (Code 39) / 0.5 – 15.2 in. (1.3 – 38.6 cm),PDF417 (10 Mil) / 0.9 – 7 in. (2.3 – 17.8 cm),Datamatrix (10 Mil) /1.1 – 7.5 in. (2.8 – 19.1 cm). |
| Scan Angle |
Roll / Pitch / Yaw: SR – Standard range: 360°, ±65°, ±60°DC – Document capture: 360°, ±65°, ±60° |
|
| Performance Characteristics |
| Imager Field Of View |
SR – Standard range: 34° V x 43° H(Vertical x Horizontal) DC – Document capture: 35° V x 44° H |
| Imaging Characteristics (DS6707 Only) |
Image (Pixels): 1.3 Megapixel: 1280 pixels H x 1024 pixels VGraphics Format Support: Images can be exported as Bitmap, Jpeg, and TiffImage Transfer Speed: USB 1.1: Up to 12 Megabits/secondRS232: Up to 115 kb baud rateImage Transfer Time: Typical USB application is ~ 0.2 seconds with a compressed Jpeg of 100 kbImaging Distance(Vertical x Horizontal):Document Sizes | Minimum Distance (approx):2 1/8″ x 3 3/8″ (5.4cm x 8.6cm)|2.4″ (6.1cm) ,4″ x 6″ (10.2cm x 15.2cm) |5.7″ (14.5cm),5″ x 7″ (12.7cm x 17.8cm) |6.9″ (17.5cm) ,8″ x 11″ (21.6cm x 28cm) |11.9″ (30.2cm) ,Ranges are from the nose of the scanner and are based on standard range focus only. |
| Interface |
DS6707: RS-232C (Standard, Nixdorf, ICL, and Fujitsu); USB (Standard, IBM SurePOS, Macintosh) and Synapse connectivity allows for connectivity to all of the above plus many non-standard interfaces.DS6708: Includes above plus IBM 468x/469x and keyboard wedge |
| Light Source |
Aiming: 650 nm laser diodeIllumination: 630 nm LED |
|
| Data Capture Characteristics |
| Decoding Capability |
2-D: MaxiCode, DataMatrix (ECC 200), and QR Code |
|
1-D: UPC/EAN and with supplementals, Code 39, Code 39 Full ASCII, Tri-optic Code 39, RSS variants, UCC/EAN 128, Code 128, Code 128 Full ASCII, Code 93, Codabar (NW1), Interleaved 2 of 5, Discrete 2 of 5, MSI, Codell, IATA, Bookland EAN, Code 32PDF417 (and Variants): PDF417, microPDF417 and composite codesPostal: U.S. Postnet and Planet, U.K., Japan, Australian, and Dutch |
|
| Power Specifications |
| Voltage and Current |
5 +/-10%VDC @ 350 mA |
|
| Environment Characteristics |
| Ambient Light Levels |
Ambient Light Immunity: Immune to normal artificial indoor and natural outdoor (direct sunlight) lighting. |
| Drop Specification |
Withstands multiple 6 ft. (1.8m) drops to concrete |
| Environment Sealing |
IP43, water and dust resistant |
| Humidity |
5% to 95%, non-condensing |
| Operating Temperature |
32° to 122° F / 0° to 50° C |
| Storage Temperature |
40° to 158° F / -40° to 70° C |
|
| Physical Characteristics |
| Dimensions |
6.55 in. H x 4.72 in. L x 2.82 in. W16.6 cm H x 11.9 cm L x 7.1 cm W |
| Weight |
6.4 oz. (182 gm) |
| Color |
Cash Register White (shown) or Twilight Black |
|
| Options |
| Accessories |
Mounting Options(Accessories): Intellistand with adjustable height: 5–10 in. (12.7–25.4 cm) and adjustable angle: 0°–90°Desktop and wall-mount holders are also available.Power Supplies: Power supplies are available for applications that don’t supply power over the host cable. |
| Regulatory Approvals |
Electrical Safety: UL6950-1, CSA C22.2 No. 60950-1, EN60950-1 / IEC60950-1Laser Safety: EN60825-1:1994 +A1: 2002 +A2 :2001, IEC60825-1, 21CFR1040.10 and 21CFR1040.11, CDRH Class II, IEC Class 2EMI/RFI: FCC Part 15 Class B, ICES-003 Class B, CISPR 22, CISPR 24 Medical electrical equipment: EN60601-1-2: 2002Environmental: Compliant with RoHS directive 2002/95/EEC |
