| Performance Characteristics |
| Communication Interface |
USB 1.1 Client for Microsoft ActiveSync |
| CPU/Processor |
MC17A: Intel PXA270, 32 bit, 312 MHzMC17T: Intel PXA270, 32 bit, 520 MHz |
| Light Source |
Visible laser diode; Class 1 |
| Memory |
MC17A: 64 MB RAM, 64 MB Flash ROMMC17T: 64 MB RAM, 64 MB Flash ROMand 1 GB SD storage |
| Operating System |
Windows CE 5.0 Professional;Pocket Internet Explorer 6.0 |
|
| Communication Modules |
| WLAN |
WLAN Wi-Fi IEEE 802.11a/b/g |
| WLAN Security |
Wi-Fi SecurityCertification:WPA2-EnterpriseAuthentication :None, PEAP-MS CHAPv2, PEAP-TLS, EAP-TLS,EAP-TTLS-CHAP, EAP-TTLS-MS CHAP,EAP-TTLS-MS CHAP v2,EAP-TTLS–PAP,EAP-TTLS-MD5, EAP-FAST, EAP-GTC,PEAP-GTC, LEAPEncryption : None, AES, TKIP, WEP-128, WEP-40/64 |
|
| Data Capture Characteristics |
| Scan Rate |
100 scans/sec |
|
| Power Specifications |
| Power Supply |
Power Source Rechargeable 2400 mAh Li-ION battery pack |
|
| Environment Characteristics |
| Ambient Light Immunity |
Tolerant to typical artificial indoor andnatural outdoor (direct sunlight) lightingconditions. Fluorescent, Incandescent,Mercury Vapor, Sodium Vapor,LED: 450 Ft Candles (4,844 Lux)Sunlight: 8000 Ft Candles (86,111 Lux)Note: LED lighting with high AC ripplecontent can impact scanning performance |
| Drop Specification |
Withstands multiple 4 ft./1.2 m drops to tileover concrete |
| Humidity |
90% RH at 50° C, non-condensing |
| Operating Temperature |
32° to 104° F/0° to 40° C |
| Storage Temperature |
4° to 140° F/-20° to 60° C |
| Tumble Specification |
500 .5m (1.64 ft.) tumbles (1,000 drops) atroom temperature |
|
| Physical Characteristics |
| Dimensions (W x H x D) |
2.3 in. H x 8.11 in. L x 3.2 in. W5.9 cm H x 20.6 cm L x 8.1 cm W |
| Display |
MC17A: 2.8 in. 320×240 QVGAMC17T: 2.8 in. 320×240 QVGA backlit |
| Keypad |
6 fully programmable keys |
| Touch Panel |
resistive touch screen |
| Weight |
9.5 oz./270 g (with battery) |
|
| Options |
| Regulatory Approvals |
Environmental ROHS compliant |
|
EMI/RFI North America: FCC Part 15Canada: ICES 003 Class BEU: EN55022 Class B, EN 301 489-1, EN 301489-17, EN 60601-1-2Australia: AS/NZS CISPRA 22 |
|
Electrical Safety Certified to UL/cUL 60950-1, EN/IEC60950-1Laser Safety IEC/FDA Class 1 in accordance withIEC/EN 60825-1 & 21 CFR 1040.10 & 11(Laser Notice No. 50) |
| User Options |
Customer Services Service from the Start with ComprehensiveCoverage |
| Warranty |
The MC17 Series is warranted against defects in workmanship andmaterials for a period of 12 months from date of shipment, providedthat the product remains unmodified and is operated under normaland proper conditions. |
