| Performance Characteristics |
| Applications Development |
Motorola Enterprise Mobility Developer Kit (EMDK) |
| CPU/Processor |
Marvell PXA320 624 MHz |
| Interactive Sensor Technology (IST) |
Motion-sensor: 3-axis accelerometer that enables motion-sensingapplications on dynamic screen orientation, powermanagement and free-fall detects |
| Memory |
128MB RAM/256MB Flash 256MB RAM/512MB Flash (Batch Only)128MB RAM/512MB Flash (WLAN Only) 256MB RAM/1GB Flash |
| Network Connections |
I/O: USB 1.1 Full Speed Host/ Client or RS232 |
| Notification |
Programmable LEDs; Audio notifications |
| Operating System |
Microsoft Windows CE 6.0 Pro or Windows Mobile6.X Classic |
|
| Communication Modules |
| WLAN |
Radio : Tri-mode IEEE® 802.11a/b/gData Rates Supported: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48 and 54 MbpsOperating Channels: Chan 1-13 (2412-2472 MHz), Chan 14 (2484 MHz)Japan only; actual operating channels/frequenciesdepend on regulatory rules and certification agencyVoice Communications: Voice-over-IP ready, Wi-Fi™ certified, IEEE 802.11a/b/g direct sequence wireless LAN, Wi-FiMultimedia™ (WMM), Motorola Voice QualityManager (VQM) |
| WLAN Antennas |
Internal antenna w/diversity |
| WLAN Security |
WPA2 (Personal or Enterprise); 802.1x; EAP-TLS;TTLS (CHAP, MS-CHAP, MS-CHAPv2, PAP or MD5);PEAP (TLS, MSCHAPv2, EAP-GTC); LEAP, EAP-FAST(TLS, MS-CHAPv2, EAP-GTC); CCXv4 certified;support for IPv6; FIPS140-2 Certified |
| WPAN Radio |
Bluetooth®: Class II, v2.1 with Enhanced Data Rate (EDR);integrated antenna |
|
| Data Capture Characteristics |
| 1D Laser Scanner (SE950) |
Resolution: 4 Mil minimum element width |
|
Scan Rate: 104 (+/- 12) scans/sec (bi-directional) |
|
Scan Angle: 47° ± 3° default; configurable narrow angle: 35° ± 3° |
|
Range on 100% UPCA Near: 1.75 in./4.45 cmat 30 ft./candles: Far: 15.35 in./39 cm |
|
Roll: ±35° from verticalPitch Angle: ±65° from normalSkew Tolerance: ±50° from normal |
| 2D Imager (SE4500-HD) |
Sensor Resolution: 752 x 480 pixels |
|
Aiming LED (VLD): 655 ± 10 nm Laser |
|
Field of View: Horizontal: 39°; Vertical: 25° |
|
Illumination Element (LED): 625 ± 5 nm LEDs (2x) |
|
Skew Tolerance: ±60°Pitch Tolerance: ±60°Roll Tolerance: 360° |
|
Ambient Light Immunity: Total darkness to 9,000 ft. candles/96,900 lux |
|
Range on 100% UPCA Near: 2.62 in./6.65 cm.at 30 ft./candles: Far: 6.1 in./15.49 cm |
| 2D Imager (SE4500-SR) |
Sensor Resolution: 752 x 480 pixels |
|
Aiming LED (VLD): 655 ± 10 nm Laser |
|
Field of View: Horizontal: 38°; Vertical: 25° |
|
Illumination Element (LED): 625 ± 5 nm LEDs (2x) |
|
Skew Tolerance: ±60°Pitch Tolerance: ±60°Roll Tolerance: 360° |
|
Ambient Light Immunity: Total darkness to 9,000 ft. candles/96,900 lux |
|
Range on 100% UPCA Near: 2.5 in./6.35 cmat 30 ft./candles: Far: 14.2 in./36.07 cm |
| Data Capture Specifications |
Scanning: Symbol SE950 for 1D bar codes; Symbol SE4500-SRimager for 1D/2D bar codes; Symbol SE4500-HD 2Dimager for 1D/2D bar codes and direct part marksOptions: Three available models: MC31X0 Turret withRotating Head; MC31X0 Straight Shooter;MC3190 Gun |
|
| Power Specifications |
| Cradle |
Single-slot USB/RS232 charging cradle with spare battery well; Four-slot charge only cradle; four slot Ethernet cradle |
| Power Supply |
Straight Shooter Imager or Laser:Rechargeable Lithium Ion 4800 mAh @ 3.7VdcSmart Battery |
|
Power Continued: Rotating Turret Laser:Rechargeable Lithium Ion 2740 mAh@ 3.7Vdc Smart BatteryGun Configurations:Rechargeable Lithium Ion 4800 mAh@ 3.7Vdc Smart Battery |
|
| Environment Characteristics |
| Ambient Light Immunity |
Tolerant to typical artificial indoor and naturaloutdoor (direct sunlight) lighting conditions.Fluorescent, Incandescent, Mercury Vapor,Sodium Vapor, LED: 450 Ft Candles (4,844 Lux)Sunlight: 8000 Ft Candles (86,111 Lux)Note: LED lighting with high AC ripple contentcan impact scanning performance. |
| Drop Specification |
Multiple 4 ft./1.2 m drops to concrete acrossthe operating temperature range, Multiple 5 ft./1.5 m drops to concrete at ambient temperature73° F/23° C; meets and exceeds MIL-STD 810G |
| Electrostatic Discharge (ESD) |
+/-15kVDC air discharge, +/-8kVDC directdischarge, +/-8kVDC indirect discharge |
| Environmental Sealing |
IP54 category 2; meets applicable EN 60529sealing specifications |
| Humidity |
5 – 95% non-condensing |
| Operating Temperature |
-4° F to 122° F/-20° C to 50° C |
| Storage & Charging Temperature |
Storage Temp.: -40° F to 158° F/-40° C to 70° CBattery Charging Temp.: 32° F to 104° F/0° C to 40° C |
| Tumble Specification |
500 1.64 ft./0.5 m tumbles (1,000 drops) at roomtemperature per IEC 68-2-32 tumble specifications |
