| Performance Characteristics |
| Connectivity |
USB 2.0 OT G connector |
| CPU/Processor |
800MHz OMAP 4 dual-core processor |
| Interactive Sensor Technology (IST) |
Motion Sensor :3-axis accelerometer provides motion-sensingfor dynamic screen orientation and powermanagementLight Sensor :Automatically adjusts display backlight brightnessProximity Sensor: Prevents unwanted keypresses in handset mode |
| Memory |
1 GB RAM/8 GB Flash |
| Notification |
LED, audio and vibration |
| Operating System |
Android 2.3 |
|
| Communication Modules |
| Magnetic Card Reader |
PaymentTransactionsIntegrated Magnetic Stripe Reader (MSR) withencrypted head (optional) |
| Voice and Audio |
PTT (client included), VoIP models (VoIP client not included); highqualityspeakerphone; wireless (Bluetooth) headset support; PTTheadset support; handset/speakerphone modes |
| WLAN |
Radio Tri-mode IEEE ® 802.11a/b/g/nData Rates: 802.11b: 1, 2, 5.5, 11 Mbps802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps802.11n: 6.5, 13, 19.5, 26, 39, 52, 58.5, 65 MbpsNote that 802.11n data rates may be higherOperatingChannels:Chan 36-165 (5180 – 5825 MHz), Chan 1-13(2412 – 2472 MHz); actual operating channels/frequencies depend on regulatory rules andcertification agency |
| WLAN Security |
Security Modes: Legacy, WPA and WPA2Encryption: WEP (40 and 128 bit), TKIP and AESAuthentication: TL S, TTL S (MS-CHAP), TTL S (MSCHAPv2), TTL S (PAP), PE AP (MS-CHAP v2), PE AP(GTC), FAST (MS-CHAP v2), FAST (GTC), LE AP. |
| WPAN Radio |
Bluetooth Class II , v 2.1 with EDR; integrated antenna |
|
| Data Capture Characteristics |
| Data Capture Options |
Imager SE4500-DL |
| Decode Capabilities |
Data Types: 1D/2D bar codes, photographs, video, signatures,documents; scans credit, loyalty and gift cards aspart of a payment transaction (MSR model only) |
|
| Power Specifications |
| Backup Battery |
NiMH battery (rechargeable) 15 mAh 3.6 V (notuser accessible) |
| Standard Battery |
Rechargeable Lithium Ion 3.7V, 2680 mAh Smartbattery |
|
| Environment Characteristics |
| Drop Specification |
Multiple 4 ft./1.2 m drops per MIL-STD 810G;multiple 3 ft./0.9 m drops to tile |
| Electrostatic Discharge (ESD) |
± 15kVdc air discharge, ± 8kVdc directdischarge, ± 2kVdc indirect discharge |
| Environmental Sealing |
IP 54 |
| Humidity |
5% to 85% RH non-condensing |
| Operating Temperature |
0° C to 50° C / 32° F to 122° F |
| Storage Temperature |
-40° C to 70° C / -40° F to 158° F |
| Tumble Specification |
250 1.6 ft./0.5 meter tumbles (500 drops) at roomtemperature; per applicable IE C tumble specifications |
|
| Physical Characteristics |
| Audio |
Speakers, microphone and headset connector(mono, 2.5 mm jack with microphone); stereoaudio through Bluetooth stereo headsets |
| Camera |
Rear-facing 8 MP auto-focus with aiming for barcode scanning and image capture. |
| Dimensions (W x H x D) |
With Magnetic Stripe Reader (MSR):5.66 in. H x 2.87 in. W x 1.25 in. D143.9 mm H x 72.8 mm W x 31.8 mm DWithout Magnetic Stripe Reader:5.66 in. H x 2.87 in. W x 0.79 in. D143.91 mm H x 72.8 mm W x 20.1 mm D |
| Display |
4.3 in. capacitive; 480 x 800; 300 NITBacklight :LE D backlight |
| Keypad |
On-screen keypad |
| Touch Panel |
Capacitive dual-touch |
| Weight With Battery |
With MSR: 9.38 oz./266.1 gWithout MSR: 9.09 oz./257.7 g |
|
| Options |
| Peripherals and Accessories |
Accessories include single and 5-slot charging cradles; single and 4-slotbattery chargers; holster and a wearable carrying solution |
| Regulatory Approvals |
Visit www.motorolasolutions.com/mc40 for regulatory information |
| User Options |
Recommended ServicesManaged Device ServiceService from the Start with Comprehensive Coverage |
| Warranty |
Subject to the terms of Motorola’s hardware warranty statement, theMC40 is warranted against defects in workmanship and materials for aperiod of 1 (one) year from the date of shipment |
