| Performance Characteristics |
| CPU/Processor |
600 MHz, ARM 11 processor, MSM 7627 |
| Interactive Sensor Technology (IST) |
Ambient LightSensor:Automatically adjusts required display backlightto maximize power efficiencyProximity sensor: Automatically detects when the user placesthe handset against head during a phone call todisable display output and touch input |
| Memory |
256 MB RAM / 1GB Flash |
| Network Connections |
USB 2.0 High Speed (host and client), WLAN,WWAN and Bluetooth |
| Notification |
Vibrator and audible tone plus multi-color LED |
| Operating System |
Microsoft® Windows Embedded Handheld™ 6.5.3Professional Edition |
| Thermal Shock |
-40°F to 158°F/-40°C to 70°C rapid transition |
| Vibration |
.02g2/Hz Random, Non-Operating, 1 hourduration per axis |
|
| Communication Modules |
| Voice and Audio |
VoWWAN: handset mode with active noisereduction, high-quality speaker phone, Bluetoothwireless headset mode |
| WLAN |
Radio Tri-mode IEEE® 802.11a/b/gData RatesSupported:1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps |
| WLAN Security |
WPA2, WEP (40 or 128 bit), TKIP, TLS, TTLS (MSCHAP),TTLS (MS-CHAP v2), TTLS (CHAP), TTLSMD5,TTLS-PAP, PEAP-TLS, PEAP (MS-CHAP v2),AES, LEAP, CCXv4 certified; FIPS 140-2 certified |
| WPAN Radio |
Bluetooth Class II, V2.0 with Enhanced Data Rate (EDR) |
| WWAN Radio |
Radio 3.5G HSDPA, Quad-Band GPRS/EDGEFrequency Band : GSM – Quad Band : 850/900/1800/1900 MHzUMTS/HSDPA – Americas: 850/1900 MHzUMTS/HSDPA – Rest of the world: 2100 MHzGPS : Integrated, Autonomous and Assisted-GPS (A-GPS) |
|
| Data Capture Characteristics |
| Scanner Options |
1D* laser with Adaptive Scan technology |
|
| Power Specifications |
| Standard Battery |
Rechargeable Lithium Ion 3.7V, 3080 mAh |
|
| Environment Characteristics |
| Drop Specification |
Multiple 6 ft./1.8 m drops per MIL-STD-810G |
| Electrostatic Discharge (ESD) |
+/-15kVdc air discharge, +/-8kVdc directdischarge, +/-8kVdc indirect discharge |
| Environmental Sealing |
IP64 per applicable IEC sealing specifications |
| Humidity |
Humidity 5% to 95% non-condensing |
| Operating Temperature |
-10°C to 50°C/14°F to 122°F |
| Storage Temperature |
-40°C to 70°C /-40°F to 158°F |
| Tumble Specification |
250 0.5 m (1.5 ft.) tumbles (500 drops); perapplicable IEC tumble specifications |
|
| Physical Characteristics |
| Camera |
Autofocus 3.2 MP with user-controllable flash;supports integrated 1D/2D bar code capture |
| Dimensions (W x H x D) |
5.6 in. L x 2.6 in. W x 1.0 in. D14.2 cm L x 6.6 cm W x 2.5 cm D |
| Display |
Outdoor-viewable 3.2 in. QVGA with backlight,240 W x 320 LBacklight LED backlight |
| Expansion Slot |
User accessible 32 GB microSD slot withSDHC support |
| Keypad |
26-key numeric |
| Touch Panel |
Polycarbonate analog resistive touch |
| Weight |
8.73 oz./247.4 g |
