| Performance Characteristics |
| Application Development Enviroment |
Microsoft Windows client CE EMDK; Motorola EMDK; MCL Designer V 3.0 (MCL Client pre-loaded on both the MT2070 and the MT2090; pre-licensed on the MT2070 only) |
| Communication Interface |
USB 2.0 Host and RS-232 |
| CPU/Processor |
IntelXScale PXA270 @312MHz |
| Memory |
64MB/64MB |
| Operating System |
Microsoft® Windows CE 5.0 |
|
| Communication Modules |
| Cordless Data Communication |
Bluetooth2.4Ghz class I radio – 300 feet (91.44 m) open air |
| Security Certification |
Certified compliant with FIPS 140-2 (available on MT2000 Series Bluetooth-enabled mobile terminals) |
| WLAN Antennas |
Internal |
| WLAN Radio |
Radio:Tri-mode IEEE® 802.11a/b/gOutput Power:100mW US and internationalData Rates Supported:802.11b – 11MBPS; 802.11a – 54MBPS;802.11g – 54MBPSFrequency Range:Country dependant: typically 2.4 to 2.5 GHz for 802.11b/g and 5.15 to 5.825GHz for 802.11a |
|
| Data Capture Characteristics |
| Decode Capabilities |
PDF417:PDF417 (Standard, Macro), Composite Codes (CC-A,CC-B,CC-C) |
|
2D:TLC-39, Aztec (Standard, Inverse), Maxicode, DataMatrix/ECC 200 (Standard, Inverse), QR code (Standard, Inverse, Micro) |
|
Postal:U.S. Postnet and Planet, U.K. Post, Japan Post, Australian Post, Netherlands KIX Code, Royal Mail 4 State Customer, upu fics 4 State Postal, USPS 4CB |
|
1D:UPC/EAN (UPCA/UPCE/UPCE1/EAN-8/EAN-13/JAN-8/JAN-13 plus supplements, ISBN (Bookland), Code 39 (Standard, Full ASCII, UCC/EAN-128, ISBT-128 Concatenated), Code 93, Codabar/NW7, MSI Plessey, I 2 of 5 (Interleaved 2 of 5 / ITF, Discrete 2 of 5, IATA, Chinese 2 of 5), GS1 DataBar (Omnidirectional, Truncated, Stacked, Stacked Omnidirectional, Limited, Expanded, Expanded Stacked, Inverse), Base 32 (Italian Pharmacode) |
| Scanner Systems |
4 configurations: 1D Laser, 1D/2D Imager,1D/2D HD Imager, DPM Imager |
|
| Power Specifications |
| Cradle |
Single slot charge only cradle, Single slot multi-interface with Bluetooth cradle, Single slot charge only fork lift cradle, 4-slot charge only cradle, 4-slot Ethernet cradle |
| Main Battery |
2400 mAh Li-Ion @3.7Vdc |
|
| Environment Characteristics |
| Ambient Light Tolerance |
Tolerant to typical artificial indoor andnatural outdoor (direct sunlight) lighting conditions. Fluorescent, Incandescent, Mercury Vapor, Sodium Vapor, LED1: 450 Ft Candles (4,844 Lux) Sunlight:8000 Ft Candles (86,111 Lux) |
| Drop Specification |
6 ft./1.8 m drop to concrete over the operating temperature range |
| Electrostatic Discharge (ESD) |
±15kVDC air discharge, ±8kVDC direct/indirect discharge |
| Environmental Sealing |
IP54 |
| Humidity |
5% to 95% non-condensing |
| Operating Temperature |
-4° to 122° F/-20° TO 50° C |
| Storage Temperature |
-40° to 160° F/-40° TO 70° C |
| Tumble Specification |
250 3.2 ft./1 m tumbles (500 drops) |
|
| Physical Characteristics |
| Dimensions (W x H x D) |
7.8 in H x 3.1 in. W x 5.0 in. D19.8 cm H x 7.8 cm W x 12.7 cm D |
| Display |
320 X 240 QVGA color graphic display |
| Keypad |
21-key single stroke numeric and shifted alpha, 4-way navigation button with 2 soft keys for application control |
| Weight |
13.5 oz/378 gm |
| Color |
Dark Gray |
|
| Options |
| Peripherals and Accessories |
Chargers:Four slot battery chargerOther Accessories:Belt holster, desk cup, IntellistandPrinters:Supports Motorola approved 3rd party printers |
| Regulatory Approvals |
Electrical Safety:Certified to UL60950-1, CSA C22.2 No. 60950-1, EN60950-1 |
|
Laser Safety:IEC Class 2/FDA Class II in accordance with IEC60825-1/EN60825-1 |
|
EMI/RFI:North American: FCC Part 2 (SAR), FCC Part 15 Subpart B – Class B, RSS210,EU: EN 301-489-1, 489-17 |
| User Options |
RECOMMENDED SERVICES:Customer ServicesService from the Start with Comprehensive Coverage1 – LED lighting with high AC ripple content can impact scanning performance |
| Warranty |
The MC2000 Series is warranted against defects in workmanship and materials for a period of 36 months from date of shipment, provided that the product remains unmodified and is operated under normal and proper conditions. |
