| Performance Characteristics |
| CPU/Processor |
Marvell PXA320 @ 806 MHz |
| Interactive Sensor Technology (IST) |
Motion-sensor : 3-axis accelerometer that enables motion-sensing applications for dynamic screen orientation, power management and free-fall detects |
| Memory |
256MB RAM/1GB Flash |
| Network Connections |
I/O :USB 2.0 Client (High Speed) or USB 1.1 host(Full Speed); USB (via 1-bay cradle) or Ethernet(via 4-bay cradle) |
| Notification |
Programmable LEDs; Audio notifications;Vibrator alerts |
| Operating System |
All models except MC959B:Windows Mobile 6.5(Classic and Professional editions)MC959B: Windows Mobile 6.1 |
| Thermal Shock |
-40° F to 158° F/-40° C to 70° C rapid transition |
| Vibration |
4g’s PK Sine (5Hz to 2KHz); 0.04g2/Hz Random(20Hz to 2KHz); 60 minute duration per axis, 3axis |
|
| Communication Modules |
| WLAN |
Radio : Tri-mode IEEE® 802.11a/b/gData RatesSupported :1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48 and 54 MbpsVoice Communications:Voice-over-IP ready, Wi-Fi™-certified, IEEE802.11a/b/g direct sequence wireless LAN,Wi-Fi Multimedia™ (WMM), Motorola VoiceQuality Manager (VQM) |
| WLAN Antennas |
Internal antenna w/diversity |
| WLAN Security |
WPA2 (Personal or Enterprise); 802.1x; EAP-TLS;TTLS (CHAP, MS-CHAP, MS-CHAPv2, PAP orMD5); PEAP (TLS, MSCHAPv2, EAP-GTC); LEAP,EAP-FAST (TLS, MS-CHAPv2, EAP-GTC); CCXv4certified; support for IPv6; FIPS 140-2 Certified |
| WPAN Radio |
Bluetooth: Class II, v2.1 with Enhanced Data Rate (EDR);integrated antenna; FIPS 140-2 compliantIrDA : Infra-red port for connection to printers andother devices |
| WWAN |
Radio : Modular 3.5G WAN (GSM HSDPA or CDMA EVDORev A)MC959B: Modular 3.5G Dual-WAN (GSM HSUPAand CDMA EVDO Rev A)Frequency Band : HSDPA: 850, 900, 1800,1900, and 2100 MHzEVDO Rev A: 850 and 1900 MHzAntenna : Internal antenna w/diversity |
|
| Data Capture Characteristics |
| 1D Laser Scanner (SE950) |
Range on 100%UPCA24 in./60 cm |
|
Scan Angle 47° ±3° default; 35° ±3° reduced |
|
Scan Rate 104 (±12) scans/sec (bi-directional) |
|
Roll ±35° from verticalPitch Angle ±65° from normalSkew Tolerance ±50° from normal |
|
Ambient LightImmunity :Tolerant to typical artificial indoor and naturaloutdoor (direct sunlight) lighting conditions.Fluorescent, Incandescent, Mercury Vapor,Sodium Vapor, LED: 450 Ft Candles (4,844 Lux)Sunlight: 8000 Ft Candles (86,111 Lux)Note: LED lighting with high AC ripple contentcan impact scanning performance. |
| 2D Imager (SE4500SR) |
Aiming LED (VLD) 655 ± 10 nm Laser |
|
IlluminationElement (LED)625 ± 5 nm LEDs (2x) |
|
Ambient LightImmunity 9,000 ft. candles/96,900 lux |
|
Skew Tolerance ±60°Pitch Tolerance ±60°Roll Tolerance 360° |
|
Focal Distance: From center of exit window: SR – 7.5 in./19 cmSensor Resolution 752 x 480 pixelsField of View Horizontal: 40°; Vertical: 25° |
| Data Capture Options |
Scanning :1D Scanner; 2D Imager; 3 MP auto-focus flashenableddigital color camera with symbologydecode software |
|
Scan Angle Optimized for scanning (15° downward angle) |
|
Options Integrated Magnetic Stripe Reader (MSR) withencrypted head (optional) |
| Exit Window |
|
|
| Power Specifications |
| Battery Performance |
Capacity: Rechargeable Lithium Ion 4800 mAh battery @3.7V – with State of Charge and State of HealthindicatorsStandby Time : 150 hoursTalk Time : 8 hours (minimum/suspend mode) |
| Cradle |
Battery Chargers/Cradles:4-slot battery charger; 1-slot battery charger;4-bay Ethernet cradle; 4-bay charge only cradle;single bay USB cradle; vehicle battery chargerusing auto charge cable; vehicle cradle withcharging capabilities |
|
| Environment Characteristics |
| Altitude |
-1,200 ft. to 12,000 ft. operational;15,000 ft.shipping |
| Drop Specification |
6 ft./1.8 m drop to concrete across the operating temperature range; meets and exceeds applicableMIL-STD-810G drop specifications |
| Electrostatic Discharge (ESD) |
±15kv Air discharge, ±8kv direct discharge,±8kv indirect discharge |
| Environmental Sealing |
IP67 sealing; meets and exceeds applicableIEC sealing specifications |
| Hazardous Location Certifications |
UL Class I, II, III Division 2, Groups A, B, C, D, F, G (SelectConfigurations Only) |
| Humidity |
5 – 95% non-condensing |
| Key And Trigger |
1 million presses |
| Lighting Immunity |
Readability: Incandescent – 450 ft. candles;Sunlight – 8000 ft. candles;Fluorescent: 450 ft. candles |
| Operating Temperature |
-4° F to 122° F/-20° C to 50° C |
| Storage Temperature |
Ambient to -40° F/-40° CAmbient to 158° F/70° C RH 95% |
| Tumble Specification |
2000 3.2 ft./1 m tumbles (4,000 hits) at roomtemperature; meets and exceeds applicableIEC tumble specifications |
