| Printing Characteristics |
| Print Method |
Thermal transfer or direct thermal |
| Print Speed |
10 ips @ 203 dpi(254mm/sec @ 8/dpmm), |
| Print Width |
4.1” max (104mm) |
| Resolution |
203 dpi (8/dpmm),optional 305 dpi (12/dpmm) |
|
| Media Characteristics |
| Label Length |
(min/max): 0.25” to 99”(6mm to 2,514.6mm) |
| Media Roll Diameter |
Roll Supply –8” diameter on a 3” core(203mm diameter on a 76mm core) |
| Media Sensor |
Transmissive (Gap, Notch, Hole), Reflective(Black Mark), Disable (Continuous Media) |
| Media Thickness |
0.0023” to 0.010”(0.06mm to .254mm) |
| Media Type |
Paper, film or synthetic thermaltransfer or direct thermal label, tag and ticketstock in roll or fanfold form |
| Media Width |
1.0” to 5.15”(22mm to 127mm) |
|
| Ribbon Characteristics |
| Ribbon Length |
450M |
| Ribbon Width |
1.55” to 5.0” (39.5mm to 127mm) |
| Core Inner Diameter |
1.0” (25.4 mm)(max): 3.3” (85mm) |
|
| Performance Characteristics |
| Memory |
32MB DRAM, 8MB FLASH |
|
| Fonts / Graphics / Symbologies |
| Character Sets |
Unicode with TrueType font support |
| Character Size |
Monotype Imaging (Agfa Monotype) – LetterGothic Bold, Courier Bold, CG Triumvirate BoldCondensed, OCR-A, OCR-B,CG Times, CGTriumvirate, CG Triumvirate Bold, (additional fontsavailable) |
| Graphics |
Graphic Support: PCX and TIFF file formats |
|
| Software |
| Driver / Utility |
Windows Drivers: Microsoft Windows 2000/XP/2003server |
|
| Environment Characteristics |
| Humidity |
0% to 90% non-condensing5% to 90% non-condensing |
| Operation Environment |
5°C to 40°C |
| Storage Environment |
-5°C to +60°C |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
11.75” W x 18.75” D x 12.125” H(298mm W x 476mm D x 308mm H) |
| Power Source |
Auto ranging power supply 90-264 VAC(48-62Hz) PFC |
| Weight |
33lbs (15Kg) |
|
| Options |
| Regulatory Approvals |
FCC-B, ICES-003,EN 55022, EN 55024, EN 61000-3-2,EN 61000-3-3, EN 60950, cMETus, CE, BSMI,CCC, C-Tick, GOST-R, MIC, Argentina “S” mark |
