| Printing Characteristics |
| Print Method |
Direct thermal (LP) or direct thermal/thermal transfer (TLP) |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:Linear bar codes: Code 39, Code 128A, B & C(User selectable/Auto), UCC/EAN- 128, Code 93, Codabar, Interleaved 2-of-5, UPC-A, UPC-E, UPC-A with 2 and 5 add on, UPC-E with 2 and 5 add on, EAN 13, EAN 8, EAN 13 with 2 and 5 add on, EAN 8 with 2 and 5 add on, Postnet (5, 9, 11, & 13 digit) Japanese Postnet, Plessey (MSI-1), MSI-3, German Post Code, RSS-14 (limited, truncated, stacked) (downloadable) |
|
2D:dimensional bar codes: MaxiCode (modes 2,3,4,6), PDF417 , MacroPDF417, QR Code (optional—with Asian font set only), Data Matrix (downloadable) |
| Graphics |
Line and box drawing PCX graphic storageBar |
|
| Software |
| Driver / Utility |
Windows® drivers (95, 98, NT v.4.0, 2000, XP)Windows printer utilities |
| SDK |
ZebraDesigner (standard) ZebraDesigner Pro (option)ZebraNet™ Bridge Enterprise (standard) Full printer management for ZPL printersPrintServer management for EPL printers ZebraNet Utilities 7.0 PrintServer management for EPL and ZPL printersFirmware |
|
| Environment Characteristics |
| Humidity |
Operating Humidity 10–90% non-condensing Storage Humidity 5–95% non-condensing |
| Operating Environment |
Operating Temp: 40° F/5° C to 105° F/41° C |
| Storage Environment |
Storage/Transport Environ. -40° F/-40° C to140° F/60° C |
|
| Physical Characteristics |
| Power Requirements |
100–240 VAC; 50–60 Hz |
|
| Options |
| Accessories |
Cutte Real-time clock Asian font set Media Adapter Guide kits (for printing narrow media—refer to tech specs for detail) Dispenser Keyboard Display Unit (KDU)1 Memory Expansion Liner-free platen (LP models only) 1 EPL products only. Check for ZPL compatibility availability. |
| Regulatory Approvals |
UL-CUL, FCC, VCCI, C-TICK, CB, CE, CCC, NOM, IRAM, BSMI, GOST (Refer to technical specification for each individual product for further details |
