| Printing Characteristics |
| Print Length |
Max. 50”(1270 mm) Min 0.2” (5mm) |
| Print Method |
Direct Thermal / Thermal Transfer |
| Print Speed |
1~5 ips(25.4~127mm/s) |
| Print Width |
Max 4.16”(105.7mm) |
| Resolution |
300 dpi(12 dots/mm) |
|
| Media Characteristics |
| Media Roll Diameter |
Max roll capacity(OD):8”(203mm) Core size:3”(76mm) / Max roll capacity(OD):7”(177.8mm) Core size:1.5”(38mm) |
| Media Sensor |
Media gap & black line Reflective sensor x 1 (Movable)& Transmissive sensor x 1 (Movable) / Head open switch / Ribbon end sensor |
| Media Thickness |
0.0025”~0.01”(0.0635~0.254mm) |
| Media Type |
Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal paper or plain paper and fabric label |
| Media Width |
Max Width:4.4”(112mm) Min Width:1”(25.4mm) |
|
| Ribbon Characteristics |
| Ribbon Length |
max 360m wax, 300m resin |
| Ribbon Roll Diameter |
max OD: 3”(76mm) |
| Ribbon Width |
1”~4” Wax, Wax/Resin, Resin (Ribbon wound ink-side in or ink-side out available) |
| Ribbon Core |
ID: 1”(25.4mm) with notch |
|
| Performance Characteristics |
| Display |
Multilingual Back-lit LCD Display 16 x 2-line,LED indicator (Ready/Media/Ribbon)x 3 |
| Interface |
Operation Interface : Button (Feed(Config.)/Pause(Calibr.)/Cancel(Reset)) x 3 Communication Interface : ” X-2300E/X-3200E: Centronics Parallel, RS-232 serial (Baud rate:2400~115200 bps), USB, PS/2 keyboard, Ethernet” |
| Memory |
16 MB DRAM (13MB User Available) 8MB Flash ROM (6MB User Available) |
| Processor /CPU Type |
32 bit RISC microprocessor |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D Barcodes : “PPLA: Code 39, UPC-A, UPC-E, Code 128 subset A/B/C, EAN-13, EAN-8, HBIC, Codabar, Plessey, UPC2, UPC5, Code 93, Postnet, UCC/EAN-128 UCC/EAN-128 K-MART, UCC/EAN-128 Random Weight, Telepen, FIM, Interleave 2 of 5 (Standard/with modulo 10 checksum/with human readable check digit/with modulo 10 checksum & shipping bearer bars), GS1 Data bar (RSS) PPLB: Code 39 Std. & Extended, UPC-A, UPC-E, UPC-Interleaved 2 of 5, Code 39 with check sum digit, Code 93, EAN-13, EAN-8 (Standard, 2 /5digit add-on), Codabar, Postnet, Code128 subset A/B/C, Code 128 UCC (shipping container code), Code 128 auto UCC/EAN code 128 (GS1-128), Interleave 2 of 5, Interleaved 2 of 5 with check sum, Interleaved 2 of 5 with human readable check digit, German Postcode Matrix 2 of 5, UPC Interleaved 2 of 5, EAN-13 2/5 digit add-on, UPCA 2/5 digit add-on, UPCE 2/5 digit add-on, GS1 Data bar (RSS) PPLZ: Code39, UPC-A, UPC-E, Postnet, Code128 subset A/B/C, Interleave 2 of 5, Interleaved 2 of 5 with check sum, Interleaved 2 of 5 with human readable check digit, Code 93, Code 39 with check sum digit, MSI, EAN-8, Codabar, Code 11, EAN-13, Plessey GS1 Data bar (RSS), Industrial 2 of 5, Standard 2 of 5, Logmars” 2D Barcodes : “PPLA/PPLZ: MaxiCode, PDF417, Data Matrix (ECC 200 only), QR code, Composite Codes, Aztec Barcode PPLB: MaxiCode, PDF417, Data Matrix (ECC 200 only), QR code, Composite Codes, Aztec Barcode” |
| Graphics |
PPLA/PPLB: PCX, BMP, IMG, HEX,GDI, Binary raster(PPLB Only) PPLZ: GRF, Hex and GDI |
| Fonts and character sets |
Internal character sets standard 5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm) Internal fonts are expandable up to 24×24 4 direction 0° ~ 270° rotation Soft fonts are downloadable |
|
| Software |
| Driver / Utility |
Software – Label editing : Windows Driver (Windows XP/ Vista /7/8 ), BarTender® from Seagull Scientific Software – Utility : Printer Utility?Font Utility |
| Emulation |
X-3200E: PPLA / PPLB X-3200ZE: PPLZ |
|
| Environment Characteristics |
| Storage Temperature |
-4°F~122°F (-20°C~50°C) |
| Operating Temperature |
40°F~100°F (4°C~38°C), 10% ~ 90% non-condensing, |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
W 250mm x H 263mm x L 418mm |
| Power Source |
Internal Universal Switching Power Supply: Input voltage: 100~240VAC 50~60Hz, 5A |
| Weight |
24lbs(11kgs) |
|
| Options |
| User Options |
Guillotine cutter, Rotary cutter, Dispenser Kit, Rewinder, Media Stacker, ArgoKee |
| Real Time Clock (RTC) |
Standard |
