| Printing Characteristics |
| Print Length |
32″ (max) |
| Print Method |
Thermal transfer / Direct thermal |
| Print Speed |
10 ips max. |
| Print Width |
4.1″ (max) |
| Resolution |
203 dpi/300 dpi (CL-S703) |
|
| Media Characteristics |
| Media Roll Diameter |
Paper Roll Size 8″ (max) |
| Media Sensor |
Label gap, notch or reflectiveMoveable media sensor: Standard |
| Media Thickness |
Paper Thickness 0.0025″ – 0.01″ |
| Media Type |
Roll or fanfold, Continuous or perforated, Die-cut labels, tags and tickets |
| Media Width |
Paper WIdth (min/max) 1.0″ – 4.65″ |
|
| Ribbon Characteristics |
| Ribbon Length |
1476′ (450m) inside or outside wound |
| Ribbon Type |
Wax, wax-resin or resin |
|
| Performance Characteristics |
| Interface |
Parallel: Standard (1284 compliant), RS232C: Standard (up to 115,200 bps),USB: Standard (version 1.1), Ethernet: Optional Internal (10/100 base T) |
| Memory |
RAM: 16.0 Mb (1.0 Mb for user data)Flash RAM (NV): 4.0 Mb (1.0 Mb for user data) |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:Code3of9, UPC-A, UPC-E, EAN-13(JAN-13), EAN-8(JAN-8), Interleaved 2 of 5,Code128, HIBC, CODABAR(NW-7), Plessey, CASE CODE, UPC2DIG ADD,UPC5DIG ADD, Code 93, Telepan, ZIP, UCC/EAN128, FIM |
|
2D:Dimensional: UPS Maxi Code, PDF-417, Data Matrix, QRCode, Aztec, RSS |
| Character Size |
7 kinds of fixed pitch fonts including OCR-A and OCR-B, Proportional fonts:CG Triumvirate smooth and bold, and True Type™Rasterizer |
|
| Software |
| Emulation |
Datamax® or Zebra® |
| SDK |
Drivers Windows Drivers: Windows 2000/XP/Vista |
|
| Environment Characteristics |
| User Options |
Cutter, label peeler, Ethernet card |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
274 x 465 x 247 mm (374 mm Height with rewinder) |
| Power Source |
100/240V, 50-60Hz Universal power supply |
| Weight |
13.3 Kg (18.4 Kg with rewinder) |
