| Scanning Characteristics |
| Depth Of Field |
5 mils: 1.5 to 14.0 cm / 0.6 to 5.5 inReflective – 100 mils: 13.0 to 530.0 cm / 5.1 to 208.7 in |
| Print Contrast |
Print Contrast Ratio (Minimum) 15% |
| Read Rate |
(Maximum) 390 reads/sec. |
| Reading Angle |
Pitch: +/- 65°; Roll (Tilt): +/- 30°; Skew (Yaw): +/- 65° |
| Scan Resolution |
(Maximum) 0.076 mm / 3 mils |
|
| Performance Characteristics |
| Illumination |
Illumination LED Array 630 – 670 nm |
| Indicators |
Datalogic ‘Green Spot’ Good ReadFeedback; Good Read LED |
| Interface |
IBM 46xx; Keyboard Wedge; OEM (IBM) USB; RS-232; USB |
| Light Source |
Aiming: 630 – 680 nm VLD |
| Reading Indicators (Beeper Operation) |
Adjustable Tone |
|
| Data Capture Characteristics |
| Decoding Capability |
Postal Codes China Post |
|
1D / Linear Codes: Autodiscriminates all standard 1D codes including GS1DataBar™ linear codes. |
|
Stacked Codes:GS1 DataBar Expanded Stacked; GS1 DataBar Stacked;GS1 DataBar Stacked Omnidirectional |
|
| Power Specifications |
| Current Consumption |
Current Operating (Typical): 285 mA @ 5 VDCStandby/Idle (Typical): 135 mA @ 5 VDC |
| Input Voltage |
4 – 14 VDC |
|
| Environment Characteristics |
| Ambient Light Levels |
0 – 100,000 lux |
| Drop Resistance |
Withstands 50 drops from 2.0 m / 6.6 ft onto a concretesurface |
| Electrostatic Discharge (ESD Protection ) |
(Air Discharge) 25 kV |
| Humidity |
(Non-Condensing) 5 – 95% |
| Operating Temperature |
Temperature Operating: -30 to 50 °C / -22 to 122 °F |
| Particulate and Water Sealing |
IP65 |
| Storage Temperature |
Storage/Transport: -40 to 70 °C / -40 to 158 °F |
|
| Physical Characteristics |
| Dimensions |
Reader: 20.3 x 7.6 x 11.4 cm / 8.0 x 3.0 x 4.5 in |
| Weight |
280.0 g / 9.9 oz |
| Color |
Black; Yellow/Black |
|
| Options |
| Accessories |
Cases/Holsters11-0109 PowerHood Padded Cover11-0138 Heated Holder, 36 V11-0139 Heated Holder, 24 V11-0140 Heated Holder, 48 V |
|
Mounts/Stands11-0110 Hands Free Stand11-0111 Universal Mounting Kit for PowerScan11-0360 Holder, Multi-Purpose, Black11-0362 Holder, Multi-Purpose, Grey7-0404 Industrial Take Up Ree |
| Agency Approvals |
The product meets necessary safety and regulatory approvalsfor its intended use.The Quick Reference Guide for this product can be referred tofor a complete list of certifications. |
| Safety Standards |
Environmental Compliance :Complies to China RoHS; Complies to EU RoHSLaser Classification :Caution Laser Radiation – Do not stare into beamEN 60825-1 Class 1 |
| User Options |
Utilities :Datalogic Aladd in™ Datalogic Aladdin configuration program is available fordownload at no charge.REMOTE HOST DOWNLOAD Lowers service costs and improves operations. |
