| Scanning Characteristics |
| Depth Of Field |
PM8300 |PM8300 AR:5 mils: 2.1 to 13.3 cm / 0.8 to 5.2 in |7.5 mils: 3.5 to 24.2 cm / 1.4 to 9.5 in, |
| Print Contrast |
(Minimum) 15% |
| Read Rate |
(Maximum) 35 +/- 5 scans/sec. |
| Reading Angle |
Pitch: 5 to 55° / -5 to -55°; Roll (Tilt): +/- 20°; Skew (Yaw): +/-60° |
| Scan Resolution |
PM83X0: 0.076 mm / 3 mils; PM83X0 Auto Range: 0.190 mm /7.5 mils |
| Width of Field |
|
|
| Performance Characteristics |
| Aiming Source |
Aiming: 630 – 680 nm VLD, Activated by ‘Double-Click’ Trigger |
| Cradle Indicator LEDs |
Battery Charging (Red); Charge Completed (Green); Power/Data (Yellow) |
| Interface |
Keyboard Wedge; RS-232; RS-485 BC8060 Only; USB; Wand |
| Light Source |
630 – 680 nm VLD |
| Reading Indicators (Beeper Operation) |
Indicators Beeper; Datalogic Three Green Lights (3GL™) Good ReadFeedback: Datalogic ‘Green Spot’ on the Code, Dual Good ReadLEDs; Good Transmission |
|
| Communication Modules |
| Cordless Communications |
Datalogic STAR Cord less Systemâ„¢ Point-to-Point Configuration Multi-Point ConfigurationEffective Radiated Power: 433.92 MHz: <10 mW; 910 MHz:<1 mWMax. Readers in Same Area: 2000 Max. Readers per Radio Receiver: 32Radio Frequency: 433.92 MHz; 910 MHzRadio Range (Open Air): 433.92 MHz: Up to 50 m / 164 ft910 MHz: Up to 30 m / 98 ftSeamless Roaming; Two Way Communications |
|
| Data Capture Characteristics |
| Decoding Capability |
1D / Linear Codes: Autodiscriminates all standard 1D codes including GS1 DataBar™linear codes |
|
Stacked Codes :Code 16K; Code 49; GS1 DataBar Expanded Stacked;GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional |
|
| Power Specifications |
| Battery Capacity |
Reads per Charge: + 60,000 |
| Battery Charging time |
External Power:4 Hours; Host Power: 10 Hours; |
| Battery Type |
Battery Type: Li-ION 2150 mAh |
| Current Consumption |
Operating (Typical): External: 1 A @ 10 V, 330 mA @ 30 V; POT:500 mA |
| Input Voltage |
External: 10 – 30 VDC; POT: 5 VDC +/- 10% |
|
| Environment Characteristics |
| Ambient Light Levels |
Immune to light exposure in offices/facilities and direct exposure tosunlight. |
| Drop Resistance |
Withstands 50 drops from 2.0 m / 6.6 ft to concrete |
| Electrostatic Discharge (ESD Protection ) |
ESD Pr otection (Air Discharge) 20 kV |
| Environment Sealing |
Particulate and Water Sealing PM8300: IP65; PM8300-D, PM8300-DK: IP64 |
| Humidity |
Humidity (Non-Condensing) 90% |
| Operating Temperature |
Temperature Operating: -20 to 50 °C / -4 to 122 °F |
| Storage Temperature |
Storage/Transport: -20 to 70 °C / -4 to 158 °F |
|
| Physical Characteristics |
| Dimensions |
Dimensions Cradle: 24.0 x 10.8 x 9.5 cm / 9.5 x 4.3 x 3.7 inPM8300: 20.7 x 11.4 x 6.9 cm / 8.1 x 4.5 x 2.7 inPM8300-D, PM8300-DK: 21.0 x 11.4 x 6.9 cm / 8.3 x 4.5 x 2.7 in |
| Display |
PM8300-D, PM8300-DK: Display Type: Graphic with backlight;Font Dimensions: User selectable (4 lines x 16 columns default);Screen Dimensions: 32 x 96 pixels |
| Keypad |
PM8300-D Only: 3-Key Keypad; PM8300-DK Only: 16-Key Keypad Weight Cradle: 380.0 g / 13.4 oz; Reader: 395.0 g / 13.9 oz |
| Color |
Yellow/Black |
|
| Options |
| Accessories |
Mounts/Stands:7-0404 Industrial Take-Up ReelHLD-P080 Desk/Wall Holder (HLD-8000)STD-P080 Hands Free Stand (STD-8000)VMK-PM80 Vehicle Mount Kit |
|
Batteries/Battery Chargers:FBP-PM80 Fixed Battery Pack (FBP-8000)MC-P080 Multiple Battery Charger, 4-Slots (MC-8000)RBP-PM80 Removable Battery Pack (RBP-8000) |
|
Base Stations/Chargers:BC8030-433, BC8030-910: Base/Charger Multi-InterfaceBC8060-433, BC8060-910: Base/Charger Multi-Interface/RS-485CHR-PM80: Charger (C-8000)SBS-PM80: Spare Battery Slot compatible with the BC8060 |
|
Cases/Holstersl:11-0138 Heated Holder, 36 VDC; 11-0139 Heated Holder,24 VDC; 11-0140 Heated Holder, 48 VDC (not for use withPM8300-D models)HLS-P080 Universal Holster (HLS-8000)PC-P080, PCD-P080 Protective Case/Belt Holster (PC-8000) |
| Agency Approvals |
The product meets necessary safety and regulatory approvalsfor its intended use.The Quick Reference Guide for this product can be referred tofor a complete list of certifications. |
| Safety Standards |
Environmental Compliance : Complies to EU RoHSLaser Classification :Caution Laser Radiation – Do not stare into beamCDRH Class II; IEC 60825-1 Class 2 |
| User Options |
Utilities :Datalogic Aladd in™ Datalogic Aladdin configuration program is available fordownload at no charge. |
