| Scanning Characteristics |
| Depth Of Field |
PM8500:-5 mils: 7.5 to 15.5 cm / 2.9 to 6.1 in ,10 mils: 5.5 to 24.5 cm / 2.1 to 9.7 in ,13 mils: 5.0 to 27.0 cm / 1.9 to 10.6 in ,20 mils: 5.5 to 36.5 cm / 2.1 to 14.4 in ,5 mils PDF: 8.0 to 18.5 cm / 3.1 to 7.3 in ,10 mils PDF: 4.0 to 25.5 cm / 1.5 to 10.0 in . |
|
PM8500wA:-5 mils: 2.5 to 10.0 cm / 1.0 to 3.9 in ,10 mils: 2.0 to 16.0 cm / 0.8 to 6.3 in ,13 mils: 1.5 to 26.0 cm / 0.6 to 10.2 in ,20 mils: 1.5 to 32.0 cm / 0.6 to 12.6 in ,5 mils PDF: 3.0 to 10.5 cm / 1.2 to 4.1 in ,10 mils PDF: 1.5 to 21.5 cm / 0.6 to 8.4 in ,7.5 mils Data Matrix/QR:5.5 to 8.5 cm / 2.1 to 3.4 in ,10 mils Data Matrix/QR:3.2 to 12.5 cm / 1.2 to 4.9 in . |
|
PM8500 HD: 3 mils: 4.5 to 8.0 cm / 1.7 to 3.1 in,5 mils: 3.5 to 9.5 cm / 1.3 to 3.8 in ,10 mils: 4.0 to 12.5 cm / 1.5 to 5.0 in ,13 mils : 5.0 to 14.0 cm / 1.9 to 5.5 in ,20 mils: 6.0 to 18.5 cm / 2.3 to 7.3 in ,3 mils PDF: 5.0 to 8.5 cm / 1.9 to 3.4 in ,10 mils PDF: 3.0 to 13.0 cm / 1.1 to 5.2 in ,4 mils Data Matrix/QR: 5.1 to 7.6 cm / 2.0 to 3.0 in ,10 mils Data Matrix/QR: 4.0 to 10.5 cm / 1.5 to 4.1 in . |
| Print Contrast Ratio |
(Minimum) 15% |
| Reading Angle |
Pitch: +/- 35°; Roll (Tilt): 360°; Skew (Yaw): +/- 40° |
| Scan Resolution |
Resolution (Maximum) High Density Model: 1D Codes: 2 mil, PDF417: 3 mil, 2D Codes:4 milStandard Model: 1D Codes: 4 mil, PDF417: 4 mil,2D Codes: 6.6 milWide Angle Model: 1D Codes: 5 mil, PDF417: 5 mil,2D Codes: 7.5 mil |
|
| Performance Characteristics |
| Aiming Source |
Aiming: 630 – 680 nm VLD; |
| Imager Sensor |
Imager Sensor 1280 x 1024 |
| Indicators |
Cradle Indicator LE Ds Battery Charging (Red); Charge Completed (Green); Power/Data (Yellow) |
| Interface |
RS-232 / USB / Keyboard Wedge / Wand Multi-Interface; RS-485: BC8060 Only |
| Light Source |
Illumination: LED Array 630 – 670nm |
| Reading Indicators |
Reading Indicators Beepers, Polyphonic; Datalogic Three Green Lights (3GL™)Good Read Feedback: Datalogic ‘Green Spot’ on the Code; DualGood Read LEDs; Good Transmission |
|
| Communication Modules |
| Cordless Communications |
Datalogic STAR Cord less Systemâ„¢ :Effective Radiated Power: 433.92 MHz: < 10 mW; 910 MHz:< 1 mWMulti-Point Configuration: Max. Readers in Same Area: 2000Max. Readers per Radio Receiver: 32Point-to-Point Configuration: Radio Frequency: 433.92 MHz;910 MHzRadio Range (Open Air): 433.92 MHz: Exceeds 50 m / 164 ft;910 MHz: Exceeds 30 m / 98 ftSeamless Roaming; Two Way Communications |
|
| Data Capture Characteristics |
| Decoding Capability |
2D Codes : Aztec Code; Aztec Mesas; Data Matrix; MaxiCode; Micro QRCode; QR Code |
|
1D / Linear Codes :Autodiscriminates all standard 1D codes including GS1DataBar™ linear codes. |
|
Postal Codes :Australian Post; British Post; Canadian Post; China Post; IMB;Japanese Post; KIX Post; Korea Post; Planet Code; Postnet;Royal Mail Code (RM4SCC) |
|
Stacked Codes :EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBarExpanded Stacked; GS1 DataBar Stacked; GS1 DataBar StackedOmnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/EComposites |
|
| Power Specifications |
| Battery |
Battery Type: Li-ION 2150 mAh |
| Battery Charging time |
Charge Time: External Power:4 Hours; Host Power: 10 hours; Reads per Charge: + 30,000 |
| Current Consumption |
Current Operating (Typical): External: 1 A @ 10 VDC, 330 mA @ 30 VDC;POT: 500 mA |
| Input Voltage |
External: 10 – 30 VDC; POT: 5 VDC +/- 5% |
|
| Environment Characteristics |
| Ambient Light |
0 – 100,000 lux |
| Drop Specification |
Drop Resistance Withstands 50 drops from 2.0 m / 6.6 ft onto a concrete surface |
| Electrostatic Discharge (ESD Protection ) |
(Air Discharge) 20 kV |
| Environment Sealing |
Particulate and Water Sealing PM8500: IP65; PM8500-D: IP64 |
| Humidity |
(Non-Condensing) 0 – 95% |
| Operating Temperature |
Temperature Operating: -10 to 50 °C / 14 to 122 °F |
| Storage Temperature |
Storage/Transport: -40to 70 °C / -40 to 158 °F |
|
| Physical Characteristics |
| Dimensions |
Dimensions Cradle: 24.0 x 10.8 x 9.5 cm / 9.5 x 4.3 x 3.7 in;PM8500: 20.7 x 11.4 x 6.9 cm / 8.1 x 4.5 x 2.7 in;PM8500-D: 21.0 x 11.4 x 6.9 cm / 8.3 x 4.5 x 2.7 in |
| Display |
PM8500-D: Display Type: Graphic with backlight; FontDimensions: User selectable (4 lines x 16 columns default);Screen Dimensions: 32 x 96 pixels |
| Keypad |
PM8500-D Only: 3-Key Keypad |
| Weight |
Cradle: 380.0 g / 13.4 oz; PM8500: 360.0 g / 12.7 oz;PM8500-D: 393.0 g / 13.8 oz |
| Color |
Yellow/Black |
|
| Options |
| Accessories |
Base Stations/Chargers :BC8030-433, BC8030-910: Base/Charger Multi-InterfaceBC8060-433, BC8060-910: Base/Charger Multi-Interface/RS-485CHR-PM80: Charger (C-8000)SBS-PM80: Spare Battery Slot compatible with the BC8060Batteries/Battery Chargers:FBP-PM80 Fixed Battery Pack (FBP-8000)MC-P080 Multiple Battery Charger, 4-Slots (MC-8000)RBP-PM80 Removable Battery Pack (RBP-8000)Cases/Holsters:11-0138 Heated Holder, 36 VDC; 11-0139 Heated Holder,24 VDC; 11-0140 Heated Holder, 48 VDC (not for use withPM8300-D models)HLS-P080 Universal Holster (HLS-8000)PC-P080, PCD-P080 Protective Case/Belt Holster (PC-8000)Mounts/Stands:7-0404 Industrial Take-Up ReelHLD-P080 Desk/Wall Holder (HLD-8000)STD-P080 Hands Free Stand (STD-8000)VMK-PM80 Vehicle Mount Kit |
| Regulatory Approvals |
Agency Approvals The product meets necessary safety and regulatory approvals for its intended use.The Quick Reference Guide for this product can be referred to for a complete list of certifications. |
| Safety Standards |
Environmental Compliance :Complies to China RoHS; Complies to EU RoHSLaser Classification :Caution Laser Radiation – Do not stare into beam; CDRH Class II;EN 60825-1 Class 1; IEC 60825-1 Class 2 |
| User Options |
Utilities:Datalogic Aladd in™ Datalogic Aladdin configuration program is available fordownload at no charge.remote host download Available on request |
