| Scanning Characteristics |
| Depth Of Field |
PD 8530:-5 mils: 7.5 to 15.5 cm / 2.9 to 6.1 in,5 mils PDF: 8.0 to 18.5 cm / 3.1 to 7.3 in,7.5 mils Data Matrix/QR:8.0 to 16.5 cm / 3.1 to 6.5 in,10 mils: 5.5 to 24.5 cm / 2.1 to 9.7 in,10 mils Data Matrix/QR:7.0 to 19.5 cm / 2.7 to 7.7 in,10 mils PDF: 4.0 to 25.5 cm / 1.5 to 10.0 in,13 mils: 5.0 to 27.0 cm / 1.9 to 10.6 in,20 mils: 5.5 to 36.5 cm / 2.1 to 14.4 in. |
|
PD 8530WA:- 5 mils: 2.5 to 10.0 cm / 1.0 to 3.9 in,5 mils PDF: 3.0 to 10.5 cm / 1.2 to 4.1 in,7.5 mils Data Matrix/QR:5.5 to 8.5 cm / 2.1 to 3.4 in,10 mils: 2.0 to 16.0 cm / 0.8 to 6.3 in,10 mils Data Matrix/QR:3.2 to 12.5 cm / 1.2 to 4.9 in,10 mils PDF: 1.5 to 21.5 cm / 0.6 to 8.4 in,13 mils: 1.5 to 26.0 cm / 0.6 to 10.2 in,20 mils: 1.5 to 32.0 cm / 0.6 to 12.6 in, |
|
PD 8530 HD:-3 mils: 4.5 to 8.0 cm / 1.7 to 3.1 in,3 mils PDF: 5.0 to 8.5 cm / 1.9 to 3.4 in,4 mils Data Matrix/QR:5.1 to 7.6 cm / 2.0 to 3.0 in,5 mils: 3.5 to 9.5 cm / 1.3 to 3.8 in,10 mils: 4.0 to 12.5 cm / 1.5 to 5.0 in,10 mils Data Matrix/QR:4.0 to 10.5 cm / 1.5 to 4.1 in,10 mils PDF: 3.0 to 13.0 cm / 1.1 to 5.2 in,13 mils : 5.0 to 14.0 cm / 1.9 to 5.5 in,20 mils: 6.0 to 18.5 cm / 2.3 to 7.3 in. |
| Print Contrast Ratio |
(Minimum) 15% |
| Reading Angle |
Pitch: +/- 35°; Roll (Tilt): 360°; Skew (Yaw): +/- 40° |
| Scan Resolution |
Resolution (Maximum)High Density Model:1D Codes: 2 mil, PDF417: 3 mil, 2D Codes: 4 milStandard Model:1D Codes: 4 mil, PDF417: 4 mil, 2D Codes: 6.6 milWide Angle Model:1D Codes: 5 mil, PDF417: 5 mil, 2D Codes: 7.5 mil |
|
| Performance Characteristics |
| Aiming Source |
Light Source Aiming: 630 – 680 nm VLD |
| Imager Sensor |
1280×1024 |
| Interface |
Keyboard Wedge; RS-232; USB |
| Light Source |
Illumination: LED Array 630 -670 nm |
| Reading Indicators |
Beepers, Polyphonic; Datalogic Three Green Lights (3GL™)Good Read Feedback: Datalogic ‘Green Spot’ on the Code,Dual Good Read LEDs |
|
| Communication Modules |
| Cordless Communications |
Datalogic STAR Cordless Systemâ„¢Effective Radiated Power: 433.92 MHz: < 10 mW; 910 MHz:< 1 mWMulti-Point Configuration: Max. Readers in Same Area: 2000Max. Readers per Radio Receiver: 32Point-to-Point Configuration: Radio Frequency: 433.92 MHz; 910 MHzRadio Range (Open Air): 433.92 MHz: Exceeds 50 m / 164 ft;910 MHz: Exceeds 30 m / 98 ftSeamless Roaming; Two Way Communications |
|
| Data Capture Characteristics |
| Decoding Capability |
2D Codes:Aztec Code; Data Matrix; MaxiCode; Micro QR Code; QRCode |
|
1D/ Linear Codes: Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes. |
|
Stacked Codes:DataBar Expanded Stacked; GS1 DataBar Stacked; GS1DataBar Stacked Omnidirectional; MicroPDF417; PDF417;UPC A/E Composites |
|
Postal Codes:Australian Post; China Post; IMB; Japanese Post; KIX Post;Planet Code; Postnet; Royal Mail Code (RM4SCC )EAN/JAN Composites; GS1 DataBar Composites; GS1 |
|
| Power Specifications |
| Current Consumption |
Operating (Typical): 550 mA @ 5 VDC, 95 mA @ 30 VDC |
| Input Voltage |
Input Voltage 5 – 30 VD |
|
| Environment Characteristics |
| Ambient Light |
0 to 100,000 lux |
| Drop Specification |
Drop Resistance Withstands 50 drops from 2.0m (6.6ft) onto a concrete surface |
| Environment Sealing |
Particulate and Water Sealing IP65 |
| Humidity |
0 to 95% non condensing |
| Operating Temperature |
Operating: -10 to 55 °C / 14 to 131 °F |
| Storage Temperature |
Storage/Transport: -20 to 70 °C / -4 to 158 °F |
|
| Physical Characteristics |
| Dimensions |
20.7 x 11.4 x 6.9 cm / 8.1 x 4.5 x 2.7 in |
| Display |
PM8500-DDisplay Type: Graphic with backlightFont Dimensions: User selectable (4 lines x 16 columns default)Screen Dimensions: 32×96 pixels |
| Weight |
295.0 g / 10.4 oz |
| Color |
Yellow/Black |
|
| Options |
| Accessories |
Cases/Holsters:11-0138 Heated Holder, 36 VDC11-0139 Heated Holder, 24 VDC11-0140 Heated Holder, 48 VDCHLS-P080 Universal Holster (HLS-8000)PC-P080 Protective Case/Belt Holster (PC-8000)Mounts/Stands:7-0404 Industrial Take-Up ReelHLD-P080 Desk/Wall Holder (HLD-8000)STD-P080 Hands Free Stand (STD-8000) |
| Regulatory Approvals |
The product meets necessary safety and regulatory approvals for its intended use.The Quick Reference Guide for this product can be referred to for a complete list of certifications. |
| Safety Standards |
Environmental Compliance : Complies to China RoHSComplies to EU RoHSLaser Classification : Caution Laser Radiation – Do not stare into beamCDRH Class II; IEC 60825-1 Class 2 |
| User Options |
Utilities :Datalogic Aladdin™ Datalogic Aladdin configuration program is available for download at no charge |
