| Scanning Characteristics |
| Depth Of Field |
4 mils: 2.0 to 11.0 cm / 0.8 to 4.3 in |
| Print Contrast |
Print Contrast Ratio (Minimum) 15% |
| Read Rate |
(Maximum) 270 reads/sec. |
| Reading Angle |
Pitch: +/- 65°; Roll (Tilt): +/- 45°; Skew (Yaw): +/- 65° |
| Scan Resolution |
(Maximum) 0.102 mm / 4 mils |
|
| Performance Characteristics |
| Interface |
RS-232 / IBM 46XX / USB Multi-Interface: QD2110RS-232 / USB / Keyboard Wedge / Wand Multi-Interface:QD2130 |
| Light Source |
Red LED 610-650 nm |
| Reading Indicators (Beeper Operation) |
(Adjustable Tone); Datalogic ‘Green Spot’ Good ReadFeedback; Good Read LED |
|
| Data Capture Characteristics |
| Decoding Capability |
Postal Codes China Post |
|
1D / Linear Codes: Autodiscriminates all standard 1D codes including GS1DataBar™ linear codes. |
|
Stacked Codes:GS1 DataBar Expanded Stacked; GS1 DataBar Stacked;GS1 DataBar Stacked Omnidirectional |
|
| Power Specifications |
| Current Consumption |
Operating (Typical): 340 mA @ 5 VDCStandby/Idle (Typical): 190 mA @ 5 VDC |
| Input Voltage |
QD2110: 4 -14 VDC; QD2130: 5 VDC +/- 10% |
|
| Environment Characteristics |
| Ambient Light Levels |
100,000 lux |
| Drop Resistance |
Withstands repeated drops from 1.5 m / 5.0 ft onto a concretesurface. |
| Electrostatic Discharge (ESD Protection ) |
(Air Discharge) 20 kV |
| Humidity |
(Non-Condensing) 5 – 95% |
| Operating Temperature |
Operating: 0 to 50 °C / 32 to 122 °F |
| Particulate and Water Sealing |
IP42 |
| Storage Temperature |
Storage/Transport: -40 to 70 °C / -40 to 158 °F |
|
| Physical Characteristics |
| Dimensions |
17.0 x 7.1 x 6.6 cm / 6.7 x 2.8 x 2.6 in |
| Weight |
121.9 g / 4.3 oz |
| Color |
Black; White |
|
| Options |
| Accessories |
Miscellaneous :11-0318 Replacement Windows, 5-Pack |
|
Mounts/Stands :11-0360 Holder, Multi-Purpose, Black11-0362 Holder, Multi-Purpose, GreySTD-QD20-BK Gooseneck Stand, BlackSTD-QD20-WH Gooseneck Stand, White |
| Agency Approvals |
The product meets necessary safety and regulatory approvalsfor its intended use.The Quick Reference Guide for this product can be referred tofor a complete list of certifications. |
| Safety Standards |
Environmental Compliance :Complies to China RoHS; Complies to EU RoHSLED Classification IEC 60825-1 Class 1 LED Product |
| User Options |
Utilities :Datalogic Aladd in™ Datalogic Aladdin configuration program is available fordownload at no charge.Remote Host Download Lowers service costs and improves operations: QD2110 |
