| Printing Characteristics |
| Print Length |
0.25″ – 99″ (6mm – 2475mm) .75″(19mm) minimum print length with optional present sensor. |
| Print Speed |
2″ – 8″ per second (51mm — 152mm) |
| Print Width |
4.094″ (104mm) |
| Resolution |
203 dpi (8 dots/mm) |
| PRINTER TYPE |
D i rect Thermal, Optional Thermal Tr a n s f e r |
| ILPC FIRMWA R E |
I n t e rnational Language Print Capabilities firm w a re allows printing of non-English character sets in over 40 languages |
|
| Media Characteristics |
| Media Sensor |
Adjustable sensor detects “see through” for liner-backed die-cut labels and tags or reflective sensing for media with black stripe sensing |
| Media Thickness |
.0025″ — .0100″ (.0635mm — .254mm) |
| Media Type |
Roll-fed or fan-fold materials, die-cut or continuous labels; perforated or continuous tag/ticket stock |
| Media Width |
1″ – 4.65″ (25mm – 118mm) |
| MEDIA WINDOW |
Clear side door panel to easily monitor media supply levels |
| S U P P LY ROLL |
8″ (203mm) maximum diameter on 1.5″ — 3″ (38mm — 76mm) core. Fan-fold stock accepted from rear of printer |
| R E V O LVING MEDIA HUBS |
S t a n d a rd in 1.5” and 3”; optional 40mm |
| LABEL BACKFEED |
For use with optional cutter |
| S TANDARD MEDIA CUTTER W/ TRAY |
Maximum Thickness .010″ (.254mm) |
| LIGHT DUTY CUTTER |
Maximum Thickness .005″ (.127mm) |
| INTERNAL REWIND |
6″ (125mm) OD capacity; label backing rewound in peel and present mode and liner rewound in batch mode with present sensor used for on-demand label dispensing (factory or field installed) |
| LABEL PRESENT SENSOR |
Used for on-demand label dispensing |
| EXTERNAL REWIND |
8″ (203mm) maximum OD capacity (full supply ro l l ) |
|
| Ribbon Characteristics |
| Ribbon Length |
1968’ (600M) in length |
| Ribbon Type |
I n d u s t ry standard ribbon widths |
| Ribbon Core |
1″ (25mm) ribbon core |
| THERMAL TRANSFER |
Simple ribbon loading featuring collapsible ribbon hub |
|
| Performance Characteristics |
| Interface |
C e n t ronics® Parallel port (IEEE 1284 compliant), RS232 at 300 to 38,400 BPS, optional Ethern e t |
| Memory |
1MB Downloadable Flash Program Memory 8MB DRAM memory |
| Networking |
M i c ro Print Server allows multiple users on various platforms to share the same printer. |
| PA S S P O RT |
P o rtable keyboard/display terminal provides interface for stand-alone printing |
| INTERNAL TWINAX/COAX INTERFA C E |
S u p p o rts printing from IBM® midrange or mainframe computers |
|
| Fonts / Graphics / Symbologies |
| Character Sets |
Modified IBM® Code Page 850; includes characters for English and most European, Scandinavian and Spanish speaking countries |
| Font Expansion/Rotation |
All fonts expandable vertically and horizontally up to 24x; fonts and graphics can be printed in four directions: 0°, 90°, 180° and 270° |
| Graphics Supported |
.PCX, .BMP and .IMG files |
| Resident Fonts |
Ten alphanumeric fonts from .035″ (.89mm) to .64″ (16.26mm) including OCR-A, OCR-B, CG Triumvirate™ scalable font f rom AGFA®. |
| Reversible Field/Mirror Image |
Any font or graphic field can be printed as a normal or reverse image |
| BAR CODE MODULUS |
5 mil to 110 mil “X” dimension in picket fence or ladder orientations |
| BAR CODES |
Code 39, Interleaved 2 of 5, Code 128 (subsets A,B and C), Codabar, LOGMARS, UPC-A, UPC-E, UPC 2 & 5 digit addendums, EAN-8, EAN-13, EAN 2 & 5 digit addendums, UPC random weight, Code 93, MSI Plessey, Universal Shipping Container S y m b o l o g y, UCC/EAN Code 128, QR Code, Postnet, Code 128 MOD 43, PDF 417, Micro PDF, UPS MaxiCode (mode 2 & 3), Datamatrix, Telepen, Aztec Code |
| I/O EXPANSION CARD |
Featuring 8MB Flash, general purpose I/O, time and date battery back up |
| FONT/FLASH EXPA N S I O N |
F e a t u res 4MB font memory and 4MB addressable Flash memory expansion |
|
| Software |
| Driver / Utility |
Used for creating label formats using virtually any Wi n d o w s®-based program. Included on Datamax Accessories CD, or via our web site at www. d a t a m a x c o r p . c o m |
| Hosts Support e d |
• Novell NetWa re • UNIX • Windows NT • LAN Manager • AppleTalk • DEC |
| P rotocols Support e d |
• IPX • TCP/IP • LPR • LAT • NetBIOS/NetBEUI |
|
| Environment Characteristics |
| User Options |
ALL OPTIONS ARE EASILY INSTALLED IN THE FIELD OR CAN BE ORDERED AS FA C T O RY INSTA L L E D |
| Operating Temperature |
40°F to 100°F (4°C to 38°C) |
| C A B I N E T |
Metal constru c t i o n |
