| Printing Characteristics |
| Print Length |
0.25” – 99.99” (6mm – 2539.75mm) |
| Print Method |
Direct thermal– Optional thermal transfer |
| Print Speed |
6 ips (152 mm/s) |
| Print Width |
4.16 in (105.7 mm) |
| Resolution |
600 dpi (24 dpmm) |
|
| Media Characteristics |
| Media Sensor |
See through” for liner-backed die-cut labelsand tags |
| Media Thickness |
0.0025” – 0.01” (0.0635mm – 0.254mm |
| Media Type |
Roll-fed: 8.0” (203.2mm) max O.D. on a 3.0”(76.2mm) core |
| Media Width |
4” models: 1.0” – 4.65” (25.4mm – 118.1mm)– 6” models: 1.0” – 6.7” (25.4mm – 170.2mm)– 8” models: 1.0” – 9.0” (25.4mm – 228.9mm) |
|
| Ribbon Characteristics |
| Ribbon Length |
Length: 1968’ (600m) |
| Ribbon Type |
Coated side in and coated side out |
| Ribbon Width |
4” models: 1.0” – 4.5” (25.4mm – 114.3mm)6” models: 2.0” – 6.7” (50.8mm – 170.2mm)8” models: 3.0” – 9.0” (76.2mm – 228.9mm) |
| Core Inner Diameter |
Core: 1.0” (25.4mm) |
|
| Performance Characteristics |
| Display |
LCD backlit graphics display |
| Memory |
16MB SDRAM / 8MB Flash |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:Linear: Code 3 of 9, UPC-A, UPC-E,Interleaved 2 of 5, Industrial 2 of 5, Std 2 of5, Code 11, Code 93, Code 128, EAN-8,EAN-13, HIBC, Codabar, Plessey, UPC 2 and5 digit addendums, Postnet, UCC/EAN Code128, Telepen, Planetcode, FIM, USPS-4 State |
|
2D :Symbologies: MaxiCode, PDF417, USD-8,Datamatrix, QR Code, Codeablock, Code 16k,Aztec, TLC 39, Micro PDF417, GS1 Databar |
| Character Sets |
Over 50 resident character sets;Unicode/UTF8 support |
| Enlargement & Rotation |
All fonts expandable vertically and horizontallyup to 24x; fonts and graphics can be printedin four directions: 0°, 90°, 180° and 270°s |
| Graphics |
PCX, .BMP, .IMG and ASCII format files |
|
| Software |
| Driver / Utility |
DMX Config: Complete printer setup utility– DMX NetManager– Embedded Network Web Pages |
| SDK |
Windows® Drivers – NT, XP, Vista |
|
| Environment Characteristics |
| Dealer Options |
SDIO / USB host interface (non-“X” models only) MCL enabled ILPC (Hangul, Simplified Chinese, and Kanji)font support |
| Factory Options |
Thermal transfer (field or factory installed) |
| Humidity |
0% – 95% non-condensing |
| Operation Environment |
Operating temperature:32°F to 100°F (0°C to 38°C) |
| Storage Environment |
Storage temperature:0°F to 140°F (-17°C to 60°C) |
| User Options |
Label present sensorPeel & present (1.5”/ 38mm min. label length) -basic or heavy-duty Internal rewinder (non-“X” models only) Powered internal rewinder (“X” models only)Standard cutter Large 240 x 320 display (non-“X” models only) Linear scanner RFID – UHF & HFGPIO interfaceWireless 802.11b/g |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
4” standard: 40 lbs. (18.2 kg)13.0”h x 12.6”w x 18.9”d (330 x 321 x 480mm)– 4” X series: 47 lbs. (21.4 kg)16.4”h x 12.6”w x 19.3”d (415 x 321 x 489mm)– 6” standard: 47 lbs. (21.4 kg)13.0”h x 15.0”w x 18.9”d (330 x 381 x 480mm)– 6” X series: 53 lbs. (24.1 kg)16.4”h x 15.0”w x 19.3”d (415 x 381 x 489mm)– 8” X series: 59 lbs. (26.8 kg)16.4”h x 17.0”w x 19.3”d (415 x 433 x 489mm) |
| Power Source |
Auto-sensing 90-132 or 180-264 VAC @47-63Hz |
