| Scanning Characteristics |
| Depth Of Field |
Minimum Element Width: 7.5 mil (0.191 mm) |
| Print Contrast |
Symbol Contrast 25% minimum reflectance difference |
| Reading Performance |
Narrow Width |Depth of Field:-7.5 mil Code 39 |6 mm – 508 mm (0.25? – 20.0?) |
| Scan Angle |
Roll, Pitch, Skew ±10°, ±65°, ±60° |
| Scan Pattern |
Retrocollective |
| Scan Speed |
Scan Speed 36 scans per second typical |
|
| Performance Characteristics |
| Interface |
Host System Interfaces RS232, Keyboard Wedge, Wand Emulation, Scanner Emulation, IBM 468X/469X, USB and Synapse |
| Light Source |
650 nm visible laser diode |
|
| Data Capture Characteristics |
| Decoding Capability |
UPC/EAN, UPC/EAN with Supplementals, GS1-128 (formerly UCC/EAN 128), JAN 8 & 13, Code 39, Code 39 FullASCII, Code 39 Trioptic, Code 128, Code 128 Full ASCII, Codabar (NW7), Interleaved 2 of 5, Discrete 2 of 5,Code 93, MSI, Code 11, Code 32, Bookland EAN, IATA, GS1DataBar (formerly RSS) |
|
| Power Specifications |
| AC Power Requirements |
4.5 to 14 VDC |
| Current Consumption |
Standby Current 50 mA |
| Standby Power |
Depending on host: host power or external power supply |
|
| Environment Characteristics |
| Drop Resistance |
Designed to withstand 50 6.5´ (2 m) drops to concrete |
| Electrostatic Discharge (ESD Protection ) |
Conforms to 20 kV air discharge and 8 kV of contact discharge |
| Environment Sealing |
Sealed to IP65 specifications |
| Humidity |
5% to 95% relative humidity, non-condensing |
| Light Levels |
Immune to direct exposure of normal office and factory lighting conditions, as well as direct exposure to sunlight;Indoor: 450´ candles/4,840 LUX; Outdoor: 4,000´ candles/43,040 LUX |
| Operating Temperature |
-30°C to 50°C (-22°F to 122°F) |
| Storage Temperature |
-40°C to 70°C (-40°F to 158°F) |
|
| Physical Characteristics |
| Dimensions |
(LxWxH) 74 mm x 122 mm x 185 mm (2.9? x 4.8? x 7.3?) |
| Weight |
356 g (12.6 oz) |
