| Scanning Characteristics |
| Motion Tolerance |
Horizontal velocity: 5 in. (12.7 cm) per second |
| Print Contrast |
25% minimum reflectance |
| Reading Perfomance |
Label Density / English / Metric : Code 39 – 3 mil/ Up to 1.21” /Up to 3.07 cm |
| Scan Angle |
Roll0 – 360°Pitch ± 65° or greaterYaw ± 60° or greater |
|
| Performance Characteristics |
| Imager Field Of View |
(Vertical x Horizontal)30° V x 40° H |
| Imaging Characteristics |
Image (Pixels) :1.3 Megapixel: 1280 pixels H x 1024 pixels VGraphics Format Support:Images can be exported as Bitmap, Jpeg, and TiffImage Transfer Speed :USB 1.1: Up to 12 Megabits/secondRS232: Up to 115 kb baud rateImage Transfer Time :Typical USB application is ~ 0.2 seconds with acompressed Jpeg of 100 kb |
| Interface |
USB and RS-232 |
| Light Source |
Aiming: 650 nm laser diodeIllumination: 630 nm LED |
|
| Data Capture Characteristics |
| Decoding Capability |
2D:MaxiCode, DataMatrix (ECC 200), QR Code,microQR, Aztec |
|
Postal :U.S. Postnet and Planet, U.K., Japan,Australian, Dutch, 4 State Postal, Post US4 |
|
DPM :Data matrix marks applied by dot peening;laser etch, ink marks, chemical etch,inkjet mold, cast and thermal spray |
|
1D :UPC/EAN and with supplementals, Code 39,Code 39 Full ASCII, Tri-optic Code 39, GS1DataBar(formerly RSS), Code 128, Code 128 Full ASCII,GS1-128 (formerly UCC/EAN-128), Code 93,Codabar (NW1), Interleaved 2 of 5, Discrete 2 of 5,MSI, Codell, IATA, Bookland EAN, Code 32PDF417 (and Variants): PDF417 and microPDF417 |
|
| Power Specifications |
| Voltage and Current |
5 ±10%VDC @ 350 mA |
|
| Environment Characteristics |
| Ambient Light Levels |
Immune to normal artificial indoor and natural outdoor(direct sunlight) lighting |
| Drop Specification |
Withstands multiple 6 ft. (1.8m) drops to concrete |
| Humidity |
5% to 95%, non-condensing |
| Operating Temperature |
32° to 122° F/0° to 50° C |
| Storage Temperature |
-40° to 158° F/-40° to 70° C |
|
| Physical Characteristics |
| Dimensions |
6.55 in. H x 5.08 in. L x 2.82 W16.6 cm H x 12.9 cm L x 7.1 cm W |
| Weight |
7.4 oz/209 g |
| Color |
Cash Register White |
|
| Options |
| Accessories |
Mounting OptionsIntellistand with adjustable height:5–10 in. (12.7–25.4 cm) and adjustableangle: 0°–90°; desktop and wall-mountholders are also availablePower Supplies: Power supplies are available for applications thatdon’t supply power over the host cable. |
| Regulatory Approvals |
Electrical Safety :UL6950-1, CSA C22.2 No. 60950-1,EN60950-1 / IEC60950-1Laser Safety :EN60825-1:1994 +A1: 2002 +A2 :2001,IEC60825-1, 21CFR1040.10 and21CFR1040.11, CDRH Class II, IEC Class 2EMI/RFI :FCC Part 15 Class B, ICES-003 Class B,CISPR 22, CISPR 24;Medical electrical equipment:EN60601-1-2: 2002Environmental :Compliant with RoHS directive 2002/95/EECC |
