| Performance Characteristics |
| Imaging Characteristics |
Type : Multiple CMOS Array ImagerIllumination :640nm, controlled by item detection systemSides Read/Scan Zone:All six (6) sides; 720° coverage |
| Interfaces Supported/Ports |
Ports : One shared POS port for USB/RS-232/IBM RS-485Three USB peripheral portsTwo powered RS-232 peripheral portsCheckpoint interlock portRemote scale display port |
|
User Interface:Soft touch capacitive pads (no buttons to breakor wear out)Wide, centrally located two-colordecode/information bar (clear for cashiers and self-checkoutusers) |
| Reading Indicators (Beeper Operation) |
Adjustable volume and beep tonesThree programmable buttons |
|
| Data Capture Characteristics |
| Decoding Capability |
2D Symbologies: Aztec; Datamatrix; MicroPDF417; MicroQRCode; PDF417; QR Code |
|
1D Symbologies: 2 of 5 (Interleaved, Discrete, IATA, Chinese); BooklandEAN; Code 128; Code 39 (standard, full ASCII );Code 93; Composite Codes; Coupon Code (UPC +EAN128); EAN128; EAN-13; EAN-8; GS1 DataBar(Omnidirectional, Truncated, Stacked); GS1 DataBarExpanded coupon; GS1 DataBar Limited; GS1DataBar Expanded (regular, stacked); JAN 8; JAN-13;MSI/Plessey; TLC -39; Trioptic Code 39; UPC-A; UPC-E;UPC-E1; 2-digit Supplementals; 5-digit Supplemental;Codabar; Pharmacode (Code 32) |
|
| Power Specifications |
| Power Consumption |
less than 5.5W while scanning |
| Voltage and Current (CR0078-S Base) |
12VDC from POS interface cable (USB PowerPlusor RS-232)Motorola 50-14000-148R power supply:90-264 VRMS (110-240 nominal),47-63Hz (50-60 nominal) |
|
| Environment Characteristics |
| EAS Support |
Checkpoint included in all configurations:Checkpoint interlock via optional cableSensormatic support:The Sensormatic ZBAMB5410 providessuperior EAS deactivation performance acrossboth horizontal and vertical planes. TheZBAMB5410 is compatible with Sensormatic’sintegrated bi-opticdeactivators (ZBSMPROE,ZBAMB9010 and ZBAMB9010-IPS) |
| Humidity |
20 to 95% non-condensing |
| Operating Temperature |
32° F to 104° F/0° C to 40° C |
| Storage Temperature |
-40° F to 158° F/-40° C to 70° C |
|
| Physical Characteristics |
| Dimensions |
Short scanner:13.9 in. L x 11.5 in. W x 4.00 in. D x 5.00 in. H,353 mm L x 292 mm W x 102 mm D x 128 mm H. |
|
Long scanner and scanner/scale:20 in. L x 11.5 in. W x 4.00 in. D x 5.00 in. H,507 mm L x 292 mm W x 102 mm D x 128 mm H. |
|
Medium scanner and scanner/scale:15.7 in. L x 11.5 in. W x 4.00 in. D x 5.00 in. H,399 mm L x 292 mm W x 102 mm D x 128 mm H. |
| Horizontal Glass |
Sapphire; integrated Produce Lift Bar |
| Management |
Remotely via SMS; locally via laptop/USB; viaUSB drive (self-configuring) |
| Scale |
30 lb. in 0.01 lb. increments/15 kg in 5 gincrementsMaximum static weight: 300 lb./136 kgScale can be added after scanner installation(most countries)Single-cable and dual-cable protocolsCompatible with Mettler and Bizerba pricecomputational scalesOptions:0-12 lb. in 0.005 lb. increments and 12-30 lb.in 0.01 lb. increments0-6 kg in 2 g increments and 6-15 kgin 5 g incrementsSingle-head and dual head remote scale displaysDual heads rotate throug 290° for widest viewingangles on the market |
| Weight |
Short scanner: 12.0 lb/5.4 kg. |
|
Long scanner: 15.2 lb./6.9 kg,Long scanner/scale: 18.3 lb./8.3 kg. |
|
Medium scanner: 13.0 lb./5.9 kg,Medium scanner/scale: 16.2 lb./7.4 kg. |
|
| Options |
| Peripherals and Accessories |
Customer side scanner (allows self-scanning of bar codes on mobilephones, loyalty cards and impulse buy items); pole display; scale |
