| Printing Characteristics |
| Print Method |
Direct Thermal/Thermal Transfer |
| Print Speed |
102mm/sec (4ips) |
| Print Width |
Max (W x P): 104 x 400 mm, (4.10” x 15.76” |
| Resolution |
12 dots/mm (305dpi) |
|
| Media Characteristics |
| Label Length |
15 to 397mm (0.59” to 15.64”), inclusive backing paper size 18 to 400mm (0.71” to 15.76“) |
| Media Core Diameter |
40mm (1.58“) |
| Media Roll Diameter |
Max outside diameter 110mm (4.33“) |
| Media Sensor |
Transmissive sensor for gap, Reflective sensor for I-mark |
| Media Thickness |
0.08 to 0.19 mm (0.003 to 0.007”) |
| Media Width |
Width: 25 to 115mm (0.99” to 4.53”), inclusive backing paper size 28 to 118 mm (1.10” to 4.65“) |
|
| Ribbon Characteristics |
| Ribbon Length |
Max Roll: 100m |
| Ribbon Width |
Max: 111mm (4.37”) |
| Core Inner Diameter |
12.7mm (0.5”) |
|
| Performance Characteristics |
| Interface |
RS232C + USB2.0 or LAN + USB2.0 IEEE 802.11g (Inc LAN), Bluetooth, IEEE1284 *RS232C + USB2.0 model only |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:UPC-A/E, EAN, CODABAR, CODE 39, CODE 93, CODE 128, UCC/EAN 128, Inter-leaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, MSI, Postnet, Bookland, EAN/UCC symbol |
|
2D:QRCode, PDF 417, MaxiCode, Data Matrix |
| Character Sets |
XU 5×9 dots, XS 17×17 dots, XM 24×24 dots, XB 48×48 dots, XL 48×48 dots |
| Character Size |
OCR-A 15×22 dots OCR-B 20×24 dots |
| Enlargement & Rotation |
0º, 90º, 180º, 270º rotation |
|
| Environment Characteristics |
| Operating Environment |
5 to 35ºC / 30 to 80% RH (with no condensation) |
| Storage Environment |
-5 to 60ºC / 30 to 90% RH (with no condensation) |
| User Options |
Cutter, Dispenser, Linerless, RFID |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
(W x D x H): 198 x 255 x 181 mm (7.80” x 10.05” x 7.13”) |
| Power Requirements |
Rated Voltage: 100 Vac – 240 Vac +/- 10% Rated Current: 1.5A Output Voltage: 25Vdc Output Current: 2 A (current peak: 13A) Frequency: 50/60 Hz |
| Weight |
3.0kg (excluding AC-Adapter) |
|
| Options |
| Regulatory Approvals |
Noise: Emission – FCC, EN55022 Class B Safety : CE, C-UL, TUV, CCC, MIC HF: EN61000-3-2 |
