| Printing Characteristics |
| Print Length |
39″/991 mm |
| Print Method |
Thermal transfer or direct thermal |
| Print Speed |
6″/152 mm per second |
| Print Width |
4.09″/104 mm |
| Printer Head |
EPL and ZPL co-resident |
| Resolution |
203 dpi/8 dots per mm |
|
| Media Characteristics |
| Media Roll Diameter |
5″/127 mm O.D. |
| Media Sensor |
Standard: Fixed reflective and transmissive sensors |
| Media Thickness |
0.003″/0.08 mm to 0.0075″/0.19 mm |
| Media Type |
Roll-fed or fan-fed, die-cut or continuous direct thermal labels with or without black line, tag stock, continuous receipt paper, wristbands |
| Media Width |
0.75″/19 mm to 4.25″/108 mm |
|
| Ribbon Characteristics |
| Ribbon Length |
244’/74 |
| Ribbon Roll Diameter |
1.36″/35 mm |
| Ribbon Width |
1.33″/33.8 mm to 43″/109.2 mm |
| Core Inner Diameter |
0.5″/12.7 mm |
|
| Performance Characteristics |
| Interface |
GX models triple interface standard RS-232 serial interface, DB-9 USB V1.1, bi-directional Parallel DB-25 female connector ZebraNet 10/100 Print Server (optional)—replaces parallel 802.11b/g wireless (optional)—replaces parallel Bluetooth wireless (optional)—replaces parallel Wireless options include LCD for visual communication |
| Memory |
8 MB SDRAM 4 MB Flash 64 MB (68 MB total) Flash with RTC (optional) |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:Bar Code Ratios: 2:1 (non-rotated) and 3:1• Linear Bar Codes: Codabar, Code 11 (ZPL), Code 128, Code 39, Code 93, Code 93, EAN-13, EAN-8, EAN-14 (ZPL), German Post Code (EPL), Industrial 2-of-5 (ZPL), Interleaved 2-of-5, Japanese Postnet (EPL), ISBT-128 (ZPL), Logmars (ZPL), MSI, Plessey, Postnet, GS1 DataBar (RSS-14), Standard 2-of-5 (ZPL), UCC/EAN-128 (EPL), UPC and EAN 2 or 5 digit extensions (ZPL), UPC-A, UPC-A and UPC-E with EAN 2 or 5 digit extensions, UPC-E, and GS1 Databar (formerly RSS) |
|
2D:2-Dimensional: Codablock (ZPL), Code 49 (ZPL), Data Matrix, MaxiCode, QR Code, PDF417, MicroPDF417, Aztec |
| Character Sets |
16 resident expandable ZPL II bitmap fonts One resident scaleable ZPL font Five resident expandable EPL2 fonts Native open type font support Unicode™ compliant for multi-language, on-demand thermal printing |
| Graphics |
Supports user-defined fonts and graphics—including custom logos ZPL II drawing commands—for boxes and linesBar |
|
| Software |
| SDK |
ZebraDesigner™ Pro ZebraDesigner ZebraNet™ Bridge Enterprise ZebraNet Utilities v7.0 Zebra Universal Driver ZebraDesigner DriverNetworking |
|
| Environment Characteristics |
| Humidity |
Operating humidity: 5% to 95% non-condensing Storage humidity: 5% to 95% non-condensing |
| Operating Environment |
Operating temperature: 40° F/4.4° C to 105° F/41° C• |
| Storage Environment |
Storage temperature: -40° F/-40° C to 140° F/60° C• |
| User Options |
Dispenser—label peel and present with label present sensor ZebraNet 10/100 Print Server—Internal Ethernet for network communication and printing802.11b/g wireless (optional)Bluetooth wireless (optional) Wireless options include LCD for visual communication |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
6.75″/171 mm6.0″/152 mm8.25″/210 mm |
| Power Requirements |
100-240VAV, 50-60HzAgency |
| Weight |
3 lbs/1.4 kg |
|
| Options |
| Accessories |
Adjustable media sensor for black line media—GX models only• Cutter for various media types—GX models only• 64 MB Flash memory with real-time clock (for total of 68 MB)—GX models only• Font Packs—Asian and other international font kits • KDU Plus™ and KDU™ keyboard display units for stand-alone printing solutions |
| Regulatory Approvals |
Emissions: FCC Part 15, Subpart B, VCCI, C-Tick Emissions and Susceptibility: (CE): EN55022 Class-B, EN61000-3-2, EN61000-3-0 and EN55024, CCC Safety: CB Scheme IEC IEC 60950:1991 +A1 +A2 +A3 +A3 +A4, TUV NRTL, IRAM NOM, AAMI, CCC |
