| Scanning Characteristics |
| Motion Tolerance |
Up to 25 in. / 63.5 cm per second |
| Print Contrast |
25% minimum reflective difference |
| Reading Perfomance |
SR Focus Range |Near |Far : 5.0mil Code 39 | 0.2″/ 0.5cm | 6.8″/ 17.3cm,13mil 100% UPCA | 0.3″/ 0.8cm |15.2″/ 38.6cm,5.0mil PDF 417 | 1.5″/ 3.8cm | 4.3″/ 10.9cm,10mil Data Matrix | 0.4″/ 1.0cm | 7.2″/18.3cm. |
| Scan Angle |
Roll 0 – 360° Pitch ± 65° or greater Yaw ± 60° or greater |
| Scan Resolution |
Minimum Resolution -SR: Code 39 4 mil; UPC 60% 5 mil; PDF417 5 mil,Datamatrix 7.5 milHD: Code 39 3 mil; UPC 60% 5 mil; PDF417 4 mil,Datamatrix 5 mil |
|
| Performance Characteristics |
| Imager Field Of View |
39° (H) x 25° (V) |
| Interface |
The scanner supports the following protocols over USB: HID Keyboard (default mode), SNAPI,COM Port Emulation, IBM SurePOS (Yellowstone)(IBM Handheld,IBM Tabletop, OPOS); The scanner supports the following protocols over RS232:Standard, Wincor Nixdorf, ICL, Fujitsu, Olivetti,Keyboard Wedge and RS-485 IBM46xx |
| Light Source |
Aiming pattern: 617 nm LEDIllumination: 625 nm LEDs |
|
| Data Capture Characteristics |
| Decoding Capability |
2D :PDF417, MicroPDF417, Composite Codes, TLC-39,Data Matrix, Maxicode, QR Code, MicroQR, Aztec |
|
Postal :Australian Post, US PLANET, Royal Mail 4 StateCustomer, US POSTNET, KIX Code (Dutch), UKPostal, Japan Post, UPU 4 State Postal FICS (PostUS4), USPS 4 State Postal (Post US3), CanadianPost (Postbar) |
|
1D: UPC/EAN, UPC/EAN with supplementals, BooklandEAN, ISSN, UCC Coupon Extended Code, Code128, GS1-128, ISBT 128, Code 39, Code 39 FullASCII, Trioptic Code 39, Code 32, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, Discrete 2of 5, Codabar, MSI, Chinese 2 of 5, GS1 DataBarvariants, Korean 3 of 5, ISBT Concat |
|
| Power Specifications |
| Power Requirements |
5 VDC ± 10% @ 275 mA (RMS typical) |
|
| Environment Characteristics |
| Ambient Light Levels |
Ambient Light ImmunityImmune to normal indoor lighting up to 1600 Lux.Immune to sunlight up to 86,000 Lux. |
| Drop Specification |
Drop Spec Withstands multiple 6 ft. (1.83 m) drops to concrete |
| Humidity |
5% to 95%, non-condensing |
| Operating Temperature |
32° F to 104° F (0° C to 40° C) |
| Storage Temperature |
-40° F to 158° F (-40° C to 70° C) |
|
| Physical Characteristics |
| Dimensions |
6.7 in. H x 3.7 in. L x 2.7 in. W(17 cm H x 9.3 cm L x 6.8 cm W) |
| Weight |
(w/o cable) 6.1 oz. (172.9 g) |
|
| Options |
| Accessories |
Hands-Free Options: Gooseneck IntellistandPower Supplies :Power supplies are available for applications thatdo not supply power over the host cable |
| Regulatory Approvals |
Electrical Safety UL60950-1 2nd ed, CSA C22.2 No. 60950-1 2nd ed,EN60950-1/IEC60950-1 2nd ed.LED Safety IEC/EN60825-1:2001, IEC/EN62471:2006EMI/RFI FCC Part 15 Class B, ICES-003 Class B, EN55022Class B, EN55024Environmental Compliant with RoHS directive 2002/95/EEC |
