| Scanning Characteristics |
| Motion Tolerance |
Up to 25 in./63.5 cm per second |
| Reading Perfomance |
Focus Range |Near |Far:-5.0 mil Code 39 |0.2 in. / 0.5 cm |6.8 in. / 17.3 cm,10 mil 80% UPCA |0 in. / 0 cm | 12.7 in. / 32.3 cm,5.0 mil PDF 417 |1.5 in. / 3.8 cm | 4.3 in. / 10.9 cm,10 mil Data Matrix | 0.4 in. / 1.0 cm | 7.2 in. / 18.3 cm. |
| Scan Angle |
Roll/Pitch/Yaw 0 – 360°, ± 65° or greater, ± 60° or greater |
| Scan Resolution |
MinimumResolution:Code 39 4 mil; UPC 60% 5 mil; PDF417 5 mil,Datamatrix 7.5 mil |
|
| Performance Characteristics |
| Imager Field Of View |
Field of View Imager: 39° (H) x 25° (V) |
| Interface |
The scanner supports the following protocolsover USB: HID Keyboard (default mode), SNAPI,COM Port Emulation, IBM SurePOS (Yellowstone)(IBM Handheld,IBM Tabletop, OPOS); The scannersupports the following protocols over RS232:Standard, Wincor Nixdorf, ICL, Fujitsu, Olivetti |
| Light Source |
Aiming pattern: 617 nm LEDIllumination: 625 nm LEDs |
|
| Data Capture Characteristics |
| Decoding Capability |
2D :PDF417, MicroPDF417, Composite Codes, TL C-39,Data Matrix, Maxicode, QR Code, MicroQR, Aztec |
|
Postal: Australian Post, US PLA NET, Royal Mail 4 StateCustomer, US POSTNET, KIX Code (Dutch), UKPostal, Japan Post, UPU 4 State Postal FICS (PostUS4), USPS 4 State Postal (Post US3) |
|
1D :UPC/EAN, UPC/EAN with supplementals, BooklandEAN, ISSN, UCC Coupon Extended Code, Code128, GS1-128, ISBT 128, Code 39, Code 39 FullASCII, Trioptic Code 39, Code 32, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, Discrete 2of 5, Codabar, MSI, Chinese 2 of 5, GS1 DataBarvariants, Korean 3 of 5, ISBT Concat |
|
| Power Specifications |
| Voltage and Current |
5 VDC ± 10% @ 275 mA (RMS typical) |
|
| Environment Characteristics |
| Ambient Light Levels |
Immune to normal indoor lighting up to 1600 Lux.Immune to sunlight up to 86,000 Lux. |
| Approved Cleansing Agents |
Isopropyl alcohol, bleach/sodium hypochlorite,hydrogen peroxide, gentle dish soap and water |
| Cradle Insertions |
Super Sani-Cloth® Wipes, Clorox® Bleach, Windex®Antimicrobial, Windex® with Ammonia D, Virex® 5 Wipes,Dispatch® |
| Drop Specification |
Withstands multiple 6 ft. (1.83 m) drops to concrete |
| Environment Sealing |
Sealing IP43 |
| Humidity |
5% to 95%, non-condensing |
| Operating Temperature |
32° F to 104° F (0° C to 40° C) |
| Storage Temperature |
-40° F to 158° F (-40° C to 70° C) |
|
| Physical Characteristics |
| Dimensions |
6.7 in. H x 3.7 in. L x 2.7 in. W17 cm H x 9.3 cm L x 6.8 cm W |
| Weight |
6.1 oz. (172.9 g) (without cables) |
| Color |
Color Healthcare White |
|
| Options |
| Accessories |
Hands-free Intellistand; power supplies (available for applications thatdo not supply power over the host cable) |
| Regulatory Approvals |
Electrical Safety:UL60950-1 2nd ed, CSA C22.2 No. 60950-1 2nd ed,EN60950-1/IEC60950-1 2nd ed.LED Safety :IEC/EN60825-1:2001, IEC/EN62471:2006EMI/RFI :FCC Part 15 Class B, ICES-003 Class B, EN55022Class B, EN55024Environmental Compliant : with RoHS directive 2002/95/EEC |
