| Printing Characteristics |
| Print Head |
Die-cast aluminum base, frame andprinthead mechanism |
| Print Length |
ZM600: with 203 dpi: 102”/2,590 mm; with 300 dpi45”/1,143 mm |
| Print Method |
Thermal transfer or direct thermal |
| Print Speed |
203 dpi: 10”/254 mm per second;300 dpi: 8”/203 mm per second;600 dpi: 4”/102 mm per second |
| Print Width |
ZM600: 6.6”/168 mm |
| Resolution |
203 dpi/8 dots per mm; 300 dpi/12 dotsper mm; |
|
| Media Characteristics |
| Label Length |
ZM600: 7.0”/178 mm |
| Media Core Diameter |
3”/76 mm |
| Media Roll Diameter |
8.0”/203 mm |
| Media Sensor |
Fixed reflective sensorAdjustable transmissive sensor media characteristics |
| Media Thickness |
0.0023”/0.058 mm to 0.010”/.25 mm |
| Media Type |
Continuous, die-cut, tags, black-markFor optimum print quality and performance, usegenuine Zebra™ supplies. |
| Media Width |
ZM400: 4.5”/114 mm |
|
| Ribbon Characteristics |
| Ribbon Length |
984’/300 m or 1476’/450 m |
| Ribbon Roll Diameter |
3:1 media roll to ribbon |
| Ribbon Type |
Ribbon wound ink-side out (ribbon woundink-side in can be used with optional ribbon spindleon ZM400) |
| Ribbon Width |
ZM600: 2.00”/51 mm to 6.85”/174 mm |
| Core Inner Diameter |
1.0”/25.4 mm |
|
| Performance Characteristics |
| Memory |
Standard: 8 MB Flash, 16 MB DRAMOptional: Factory Installed 64 MB Flash |
|
| Fonts / Graphics / Symbologies |
| Barcode Symbologies |
1D:Linear Bar Codes: Code 11, Code16k, Code 39,Code 93, Code 128 with subsets A/B/C and UCCCase C Codes, UPC-A, UPC-E, EAN-8, EAN-13, UPCand EAN 2 or 5 digit extensions, Plessey, Postnet,Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5,Logmars, MSI, Codabar, Planet Code |
|
2D:Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF417, TLC 39,GS1 DataBar (RSS), Aztec |
| Character Sets |
Native open type font support Global Printing—Unicode™ compliant for fast multilanguage,on demand thermal printing right out ofthe box. |
| Enlargement & Rotation |
Contains UFST® from Monotype Imaging Inc. |
| Graphics |
Supports user-defined fonts and graphics—includingcustom logosZPL II drawing commands—for boxes and lines |
|
| Software |
| SDK |
ZebraDesigner™ Pro ZebraDesigner for XML ZebraNet™ Bridge Enterprise ZebraNet Utilities v 7.0 Zebra Universal DriverZBI-Developer™ Additional scalable and bitmapped fonts available |
|
| Environment Characteristics |
| Humidity |
Operating humidity: 20-85% non-condensingStorage humidity: 5-85% non-condensing |
| Operation Environment |
32º F/0º C to to 104º F/40º C (Direct Thermal)40º F/5º C to 104º F/40º C (Thermal Transfer |
| Storage Environment |
-40º F/-40º C to 140º F/60º C |
|
| Physical Characteristics |
| Dimensions (W x L x H) |
Width: 10.9”/278 mm Height: 13.3”/338 mmDepth: 18.7”/475 mm |
| Power Source |
Universal auto-ranging (PFC-compliant) power supply90-265 VAC; 48-62Hz |
| Weight |
Weight: 32.4 lbs/15 kg |
|
| Options |
| Accessories |
Factory installed 64 MB Flash memory optionCutter with catch trayPeel—a front mount, passive peel option with noliner take-upLiner take-up (works with peel option)—full roll linertake-up spindle (fits standard base, ZM400 only)Rewind—internally rewinds full label roll on 3” core(comes with taller, non-standard printer base) RS-422/485 serial port adapterOptional ribbon spindle to support ribbon woundink-side in (ZM400 only) |
| Regulatory Approvals |
IEC 60950-1, EN55022 Class B, EN55024,EN61000-3-2,3Markings: cULus, CE Marking, FCC-B, ICES-003,VCCI, C-Tick, NOM, CCC, GOST-R, BMSI,S-Mark, MIC, ZIK |
